IP Dust Test Chamber

Whats/App: +86 156 1874 6768

Web: standard-groups.com

Features and Benefits

1. As one of leadingdust chamber suppliers, our Dust Test Chambers are from 800L, 1000L, 1500L to 2000L, a variety of models are available. In addition, the size and performance can be customized according to the customer's needs.

2. A wide range of Dust Test Chambers meet various standards such as IEC60529 IP5X, IP6X and MIL-STD-810.

3. The dust ingress test chamber is easy to operate, can be programmed according to the requirements for automatic operation, can be connected to the computer and the laboratory operating system, so as to achieve integrated and remote control.

4. After effectively communicating with the customer about the test requirements, the model can be accurately determined and the product can be delivered quickly.

Specifications

Model

STD DI-800

STD DI-1000

STD DI-1500

STD DI-2000

Internal Dimension (mm)

800*1000*1000

1000*1000*1000

1000*1500*1000

1000*2000*1000

Overall Dimension (mm)

1040*1450*1960

1330*1450*1960

1330*1950*1990

1330*2450*1990

Useful Volume (L)

800

1000

1500

2000

Temperature Range

Ambient ~ +50℃

Humidity Range

< 30% RH

Normal Wire Diameter

50um

Nominal Width of a Gap Between wires

75um

Fight Time

0 ~ 99H59M

Blowing Time

0 ~ 99H59M

Specimen Power Outlet

Dust-proof socket 16A

Controller

Programmable color LCD touch screen controller, Ethernet connection

Safety Device

Over-temperature Protection; Over-current Protection;

Earth Leakage Protection; Phase Sequence Protection

Exterior Material

A3 Steel Plate with protective coating

Interior Material

SUS304 stainless steel

Standard Configuration

Sample shelf, dust wiper, talcum powder(5kgs)

Power

AC380V 50Hz
