Cleveland Open Cup Auto Flash Point Analyser, ISO2592，auto ignition flash point equipment
Products:
The instrument complies with ISO2592 "petroleum products of flash and fire assay (Cleveland open cup)," the other standard methods, the use of microcomputer technology control, automated work process, color touch-screen operation, high-speed thermal the printer automatically print the results, and has failed self-test function, and it could be used in petroleum, chemicals, power, environmental protection, railways, research to do flash point testing.
Model: STD-ISO 2592
Standard: ISO2592
Main Features:
1.7-inch color touch-screen LCD display, English interactive display interface;
2. PID control algorithms automatically adjust the heating curve according to standards;
3. Equipped with automatic detection chip atmospheric pressure to measure atmospheric pressure.
4. A big size data storage function, can store 300 results for any time historical record;
5. Automatic error correction system, automatic stop when temperature is alarm;
6. Mixing, ignition, detection, alarm, cooling, print is automatically controlled;
7. The testing process automatically lidopenning, ignition, alarm, cooling and printing;
8. Platinum alloy heating wire ignition, stable and reliable, high precision;
9. Can be connected to a laptop via USB interface communication, compatible withWINDOWSXP /WINDOWS7 system, network management.
10. Multilingual language operation.
11 ,Warming, openings, fire, alarm, cooling, printing is automatically controlled by system.
12. High-speed signal processors, high-precision analog / digital conversion circuit, stable instrument performance and test accuracy.
Technical Parameters:
| 1. Display Mode: | 7-inch color touch-screen LCD display |
| 2. Measurement: | Differential detection type thermocouple |
| 3. Measuring Range: | 20 -400 ºC |
| 4. Repeatability: | ±2ºC |
| 5. Printer: | High-speed thermal printer, 56 mm paper width |
| 6. Ignition: | Electronic ignition |
| 7. Temperature Detection: | Imported precision platinum resistance |
| 8.Self-test function: | Printer, ignition, solenoid valve, the lift arm is detected, the ignition sweep and so draw rod |
| 9. Power Consumption: | <700W |
| 10. Use of the environment: | 10ºC-45ºC,30-80% Temperature of 10 ºC -45 ºC, humidity 30-80% |
| 11. Dimensions: | 450×380×290mm |
| 12. Power : | AC220V±10% |
| 13. Weight: | About 15 kg |
