Hydropro Hydrostatic Head Tester
Производитель: Шанхайская компания Qianshi Precision Electromechanical Technology Co., Ltd
Все товары поставщика
Все товары поставщика
Hydropro Hydrostatic Head Tester - Non-woven and Geomembrane - standard
Standards:
AATCC 127 Option 2, ISO 811, ISO 1420, GB/T4744， FZT01004, DIN53886, JIS L1092, EN20811
Applications:
High pressure-servo Fabric Hydrostatic Head Pressure Test Machine is used to test the waterproof properties of fabric through waterproofing work such as canvas, coated fabrics,hood fabric, tarpaulin, rain-proof fabrics and geotextile.
Product Information:
Application：
High pressure-servo Fabric Hydrostatic Head Pressure Test Machine is used to test the waterproof properties of fabric through waterproofing work such as canvas, coated fabrics,hood fabric, tarpaulin, rain-proof fabrics and geotextile.
Standards:
AATCC 127 Option 2, ISO 811, ISO 1420, GB/T4744，FZT01004, DIN53886, JIS L1092, EN20811
Feature：
1. The pressure using dynamic feedback regulation effectively prevent pressure overshoot.
2. Japan Panasonic servo motor and drive system, 16-bit A/D conversion.
3. Hydrostatic head tester -whole machine with aluminum alloy structure.
4. Sensor protection: automatic overload protection ( automatic switching of multi-sensor range).
Parameters:
1. Measuring range: 500pa-200kpa(5-2000cmH2O)
2. Resolution: 1 pa
3. Accuracy: 0.2%FS
4. Pressure speed: 50--900mm/min (500pa-9kpa;5mbar-90mbar)stepless adjustable
5. Accuracy error: ≤1 mm
6. Specimen holder Pneumatic Grip Dimension: 100cm2
7. External dimension: 600×400×780mm(L×W×H)
8. Weight:50 kg
9. Power source: Ac 220V±10% 50HZ 100W or specified
