Water Cooled Xenon Arc Lamp Weather-Resistant Test Chamber
Все товары поставщика
Water Cooled Xenon Arc Lamp Weather-Resistant Test Chamber - Weather resistance and aging test equipment price - standard
Standards:
GB/ t1865-97 (2007), GB/ t9344-88, GB/ t16422.2-99, GB/ t2423.24-1995, ASTMG155, ISO10SB02/B04, SAEJ2527, SAEJ2412, etc
Applications:
Automobile industry, communication industry, construction industry, aerospace, naval ships and ships, electronics industry, clothing industry, luggage industry, furniture industry, etc.
Product Information:
Product Description:
The Water Cooled Xenon Arc lamp Weather-resistant Test Chamber is commonly used in industries such as automotive, aerospace, and material science for evaluating the durability, performance, and reliability of products under harsh environmental conditions.
The xenon arc lamp simulates the whole sunlight spectrum to reproduce the destructive light waves in different environments. Equipped with the appropriate filter atmosphere arc lamp to maintain at that time, the ultraviolet radiation is similar to the sun and the spectral energy distribution of visible area, scientific research and in the fields of aviation, automobile, home appliances, the necessary test equipment, this equipment for scientific research, product development and quality control to provide the corresponding environmental simulation and accelerated aging test. Used for schools, factories, research and other units.
Xenon arc Testing Chamber is used for the selection of new materials, the improvement of existing materials or evaluating the changes in product formulation that affect product durability. This is an ideal instrument for total Accelerated Light Stability and Weathering Testing; And can be used to test for light stability quickly.
Main Parameter:
(The above parameters are machine standard parameters and can be customized according to your requirements)
| Studio size (mm) | 750*500*600mm |
| External size (mm) | 1350*1200*1750 (length * depth * height) |
| Temperature range | normal temperature ~80ºC |
| Humidity range | light cycle 45% ~ 95% R.H, dark cycle 30% ~ 95% adjustable |
| Experimental blackboard temperature | adjustable from 45ºC to 100ºC (deviation ±3ºC) |
| Temperature fluctuation | ≤±0.5ºC |
| Temperature uniformity | ≤±2.0ºC |
| Humidity fluctuation | ≤±2% |
| Glass filter | borosilicate glass |
| Xenon light source | imported air-cooled xenon arc light source |
| Xenon lamp power | 2.5kw, xenon lamp power :2.5kw ×3 = 5.4kw, life :1200 hours |
| Rainfall time | 1 ~ 9999 minutes, continuous rainfall adjustable |
| Rainfall cycle | 1 ~ 240 minutes, interval (off) rainfall adjustable |
| Water spray nozzle aperture | Ф 0.8 mm (return hose ultra-fine filters to prevent the nozzle blocking) |
| Spraying period (spraying time/no spraying time) | 18min/102min or 12min/48min(spraying time/no spraying time) spraying pressure0.12 ~ 0.15 Mpa |
| Water pressure | 0.12 ~ 0.15kpa |
| Sample rack | sample tray size :75*300mm |
| Continuous adjustable time of illumination cycle | 1 ~ 999 hours |
| Xenon lamp spectral wavelength | 290nm ~ 800nm adjustable, irradiation range: 500W ~ 1200W/m2(adjustable). |
| Distance from the arc center to the sample | 250 ~ 300mm |
| Effective exposure area | 6400Cm2 |
| Heating power | 4.5kw |
| Humidifying power | 3KW |
Material of Test Chamber:
| 1) Exterior material | SUS 201 double layer stainless steel plate |
| 2) Inner material | SUS 304 matt stainless steel plate |
| 3) Thermal insulation material | rigid polyurethane foam + high-efficient thermal insulation glass wool |
| 4) Sample frame | all stainless steel, samples fixed position adjustable, standard stamping forming sample |
| 5) Door | silicone rubber sealing device |
