Paper thickness tester
Все товары поставщика
Paper thickness tester - Other test instrument - standard
Product Introduction:
Paper thickness tester is suitable for measuring the thickness of various paper （including toilet paper）， cardboard, corrugated cardboard, tobacco sheet, plastic film and other sheet materials.
Meet the standard:
ISO534, GB/T451.3, GBT24328.2, QB/T1055
Technical features:
Chinese touch screen display, friendly man-machine interface operation, automatic completion of the test, with the test data statistical processing function, micro printer output.
Technical parameters:
Measuring range: （0——5） mm （measuring paper, sheet）， （0——20） mm （measuring cardboard）
Accuracy: ±0.001mm or ±0.5%
Flatness of two measuring surfaces: ≤0.001mm
Test contact area: （2±0.05）cm², （10±0.2）cm²
Contact pressure （can be set arbitrarily） : （0.5-500）kPa, （0.1-100）kPa
Test speed: ≤3mm/s
Weight: About 20kg
Power supply: AC220V, 50Hz
Dimensions: 330×340×350mm
