Fabric Tensile Testing Machines
Все товары поставщика
Fabric Tensile Testing Machines - Material and Parts of Automotive - standard
Standards:
ASTM D5034，ASTMD 2261，ASTM D434，GB/T3923、GB/T3917、GB/T13772、FZ/T80007.1，ISO5081，DIN53859，DIN53858，BS3320、4303、2576、2543
Applications:
Mainly used in a variety of materials with its constant speed stretching; tearing, stripping, fixed load, fixed elongation, elastic recovery rate, the top break and other test experiments.
Product Information:
Fabric strength machine
Application
Fabric strength machine, universal strength machine and Material strength machine mainly used in a variety of materials with its constant speed stretching; tearing, stripping, fixed load, fixed elongation, elastic recovery rate, the top break and other test experiments.
Product Description:
Mainly used for a variety of materials, fabrics, non-woven materials, also with the fixed speed stretching; tearing, peeling, fixed load, set elongation, elastic recovery rate, bursting, which can also provide with functional instrument friction test according to user requirements.
Parameter description:
1, the test mechanism: CRE testing mechanism, high-speed sampling
2, controlling method: computer control, liquid crystal display; print output
3, PC-line: record the whole process of testing, access to a powerful analysis, real-time display the data on curve, breaking strength, elongation, yield stress, yield elongation, elongation off, the initial modulus, the CV value and a number of statistical indicators
4, measuring range: 100.0N, 2500N, 5000N, optional
5, the tensile speed: 2mm / min ~ 1200mm / min arbitrary
6, the return speed: 2mm / min ~ 1000mm / min
7, time stretching: 20s ± 3s, 30s ± 5s optional
8, the maximum number of stretch: 99 times
9, the average number of groups: 2 to 30 times (can be the average of meridians, zonal average)
10, elongation range: 200mm gauge elongation of up to 350%
11 gauge: 25 ~ 500mm between the arbitrary regulation
12, Dimensions: 690mm × 480mm × 1270mm.
13, power supply: AC220V, 50HZ
14, Weight: about 130 kg
Standard configuration:
1, a host
2, three sets of fixtures: breaking the top, torn, strength
Optional configuration:
1, a computer
2, a printer
