Protective Clothing Vertical Flame Spread Testeris made according to ISO 15025 standard. It can test the flame spread state under the small flame .

It is used to simulate the protective clothing is at the risk of ignition to assume the flame spread performance .

It is also suitable for the fabric material or other similar functional use of combustible materials .

The instrument is applied for the testing of fire hazard using com-bustible materials, like fabric or other similar functional materials.

BS EN ISO 15025:2002

Items:Parameters

Dimension:1200mm X 600mmx 1200mm

Timer accuracy ：0.1s

Power supply ：220v，50/60Hz

1. The combustion chamber is made of stainless steel; nice, corrosion-resistant;Dimension: 1200mm X 600mmx 1200mm

2. All sample holder is made of stainless steel manufacturing,corrosion resistance;

3. Standard burner; flame height level 25mm ± 2mm; vertical 40mm ± 2mm; nozzle opening 0.19mm;

4. The time is automatically recorded, automatic storage; timer accuracy 0.1s;

5. PLC with touch screen control system; to achieve more intelligent test; automatically record test data, automatic storage;

6. Imported brands gauge and control valve, the gas pressure is more stable;

7.Imported needle valve, precise control of the flame height; flame is more stable;

8.High intelligence, simple operation, easy to operate;

9.With the bottom surface of the combustion and combustion of two sample holder; made of stainless steel;

10.Automatic ignition system, automatically turns off;

11.Equipped with a flame height gauge;

12.Pulsed high voltage electronic automatic ignition.

13.Timing button with the PLC automatically record storage combustion time-consuming.

14.Without holding the stopwatch or timer manuscript; the system automatically records the test of time, and generate test reports;

15.The test time and time plus a touch screen can be set to fire. Meet a variety of test standards;

16.Surface combustion and bottom surface combustion burner test program on the touch screen can be switched.
