Fiber Crimp Elasticity Tester ISO 2060 ASTM D885
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Fiber Crimp Elasticity Tester is a specialized instrument designed to measure the crimp degree, crimp elasticity, and crimp recovery rate of fibers with linear densities from 1 to 22 dtex. It is widely used in fiber research, production, and quality inspection departments to evaluate both natural and chemical fibers, providing accurate and repeatable measurements for fiber performance analysis and process optimization.
Application
(1) Testing crimp degree and crimp recovery rate of synthetic fibers such as polyester, nylon, acrylic, and rayon.
(2) Evaluating natural fibers including cotton, wool, and blended fibers for crimp elasticity.
(3) Fiber research and development in textile laboratories and nonwoven material production.
(4) Quality control in fiber spinning, carding, and finishing processes.
(5) Comparative studies of crimp performance for recycled or blended fibers.
(6) Assessment of fibers used in technical textiles for automotive, medical, and smart textile applications.
(7) Education and training purposes in fiber science and textile engineering programs.
Standards
(1) GB/T 14338-2008: Test method for crimp and crimp elasticity of staple fibers.
(2) GB/T 14338-2022: Updated national standard for crimp performance of man-made staple fibers.
(3) ISO 2060: Determination of fiber fineness by electrical or physical methods (applied analogously).
(4) ASTM D885: Standard test methods for crimp characteristics of textile fibers.
(5) EN 1269-1: Test methods for staple fibers—crimp characterization and recovery rate measurement.
(6) JIS L 1013: Methods for evaluating crimp and elasticity of textile fibers.
Features
(1) Standard Compliance: Fully adheres to national and international standards for fiber crimp testing.
(2) Broad Applicability: Supports fibers with linear densities from 1 to 22 dtex, including natural and chemical fibers.
(3) Versatile Tension Loading: Multiple tension ranges (0–5 mN, 0–10 mN, 0–25 mN) with fine minimum divisions for precision control.
(4) High Measurement Resolution: Displacement resolution of 0.01 mm ensures accurate measurement of fiber elongation.
(5) Automated Testing: Automatic timing with selectable durations of 30s, 60s, and 120s for consistent results.
(6) Clear Observation: Equipped with LED lighting to facilitate monitoring of the fiber sample during testing.
(7) Comprehensive Analysis: Measures crimp degree, crimp elasticity, and crimp recovery rate.
(8) Supports Key Departments: Essential for fiber research, production, and inspection laboratories.
Parameters
| Parameter | Specification |
|---|---|
| Tension loader range | 0–5.00 mN (min division 0.01 mN), 0–10.00 mN (min division 0.02 mN), 0–25.00 mN (min division 0.05 mN) |
| Initial length | 20 mm |
| Lower clamp stroke | ≤30 mm |
| Displacement resolution | 0.01 mm |
| Timing | Automatic, selectable: 30s, 60s, 120s |
| Lighting | LED lights |
| Crimp count length | 25 mm |
| Power supply | AC 220V, 50 Hz |
