Qinsun Xenotest 220

Standards

• ISO 105-B02: Lightfastness testing for colored textiles.
• AATCC TM16 (Option 3): Accelerated weathering for textiles under controlled conditions.
• Marks & Spencer C9/C9A: Retail-specific durability protocols for apparel and home textiles.

Product Advantages

1. Unmatched Capacity:
   • Tests38 samples simultaneously, doubling the throughput of the 150 S+ model within the same footprint.
   • Optimized for high-volume testing without compromising precision.
2. Cost Efficiency:
   • Air-cooled designreduces energy consumption by 30% compared to water-cooled alternatives.
   • 60-liter integrated water tankminimizes refill frequency for ultrasonic humidification.
3. Precision Control:
   • Direct adjustment of irradiance (300–400 nm), black label temperature, chamber humidity, and airflow.
   • Dual temperature control(up to 100°C) for black label and chamber, managed via fan-assisted differential regulation.
4. User-Centric Design:
   • 220+ Model: Color touchscreen interface with multi-language support (10+ languages) and 10 programmable test presets.
   • Advanced Diagnostics: Real-time error alerts and internal data logging via storage chip.
5. Compliance & Versatility:
   • Preconfigured for ISO and AATCC standards, with customizable end-of-test triggers (sunlight exposure, runtime, or illumination dose).

Product Features

• Illumination System:

  • 2200W air-cooled xenon lamp tube for stable UV-A to visible light output.
  • Long-life filter technologyensures consistent spectral distribution (300–400 nm) over 1,500+ hours.
• Sample Handling:
  • XENONSENSIV® Sample Rack: Holds 19 containers (38 textile samples) with integrated sensors for irradiance (W/m²) and black label temperature (°C) monitoring.
• Climate Control:
  • Ultrasonic humidification with automatic water replenishment.
  • Relative humidity range: 10%–70% RH (non-condensing).
• Connectivity:
  • Ethernet & RS232 interfacesfor data export.
  • XenoTouch Attachments: Remote monitoring, alerts, and cloud integration (Optional 1/2/3).
• Safety & Durability:
  • UV-blocking observation window for safe sample inspection.
  • Robust construction with corrosion-resistant materials for industrial environments.

Technical Parameters

Accessories & Options

1. XenoTouch 1/2/3:

   • Remote control, real-time alerts, and web-based monitoring.
2. Dual Temperature Control Kit:
   • Simultaneous management of chamber and black label temperatures.
3. Extended Warranty:
   • 3-year coverage for lamp, filters, and electronics.
4. Custom Filter Sets:
   • Tailored spectral ranges for specialized textiles (e.g., UV-enhanced for outdoor fabrics).
