Rapid Crack Propagation Tester / RCP Tester
Standard
ISO 13477: Designed exclusively for determining critical pressure (Pc) and temperature (Tc) in polyethylene pressure pipes during rapid crack propagation.
Product Advantages
1. Robust & Adaptable Design
Universal Compatibility: Tests pipes fromØ50mm to Ø500mm(1629/1671 models) with interchangeable fixtures.
Motorized Precision: Servo-driven actuator ensures repeatable impact energy delivery.
2. Cutting-Edge Control
Touchscreen Interface: Pre-programmed ISO 13477 test sequences with adjustable strike velocity (10/15/20 m/s).
Real-Time Adaptation: Auto-adjusts strike force based on pipe stiffness feedback.
3. Safety & Accuracy
Pressure Lockout: Prevents test initiation until safe containment is confirmed.
Laser Alignment: Sub-millimeter positioning of impact head and specimen.
4. Automated Workflow
Cryogenic Feeder (1671 Model): Robotic arm loads pre-chilled samples (-20°C to -40°C) into test chamber.
Self-Centering Chucks: Automatic pipe alignment reduces setup time by 60%.
5. Data Integrity
High-Speed Cameras: 2.000 fps recording of crack initiation and propagation.
AI-Assisted Analysis: Machine learning algorithms quantify crack velocity (±0.1 m/s accuracy).
Technical Parameters
| Specification | Model 1629 | Model 1671 |
|---|---|---|
| Max. Pipe Ø | 250 mm | 500 mm |
| Impact Velocity | 10/15/20 m/s | 10/15/20 m/s |
| Test Pressure | 0–25 Bar | 0–25 Bar |
| Temperature Range | -20°C to +60°C | -40°C to +60°C |
| Power Supply | 220V/50Hz (110V/60Hz) | 380V/50Hz 3-phase |
| Footprint | 1.500mm × 1.200mm | 2.400mm × 1.800mm |
| Weight | 850 kg (net) | 1.600 kg (net) |
