Fatigue Endurance Tester for Dental Implants
Standard
ISO 14801:2016: Specifies dynamic fatigue testing protocols for endosseous dental implants, including load ratios, frequency, and failure criteria.
YY/T 0521-2018 (China): Defines methodologies for evaluating the fatigue strength of dental implant-abutment complexes under cyclic loading.
Product Advantages
Electromagnetic Precision: Novel servo motor technology ensures backlash-free operation with 0.001 mm displacement resolution.
Biorelevant Simulation: Integrated 37°C water bath system replicates physiological conditions for in vitro corrosion testing.
Universal Fixturing: Adjustable angle clamps accommodate straight/angulated implants (0°–25° pre-set options).
High-Frequency Stability: 20 Hz operation with ±0.05% load accuracy across 2 million cycle tests.
Compact Design: Benchtop footprint (450 × 400 × 600 mm) suits laboratory environments.
Regulatory Compliance: Pre-loaded ISO 14801 protocols with automated data reporting for FDA/CE submissions.
Product Features
Electromagnetic Servo Actuator: 600 N dynamic load capacity with programmable R=0.1–10 ratios.
Dual Sensor System: 0.01 N resolution load cell + 0.001 mm LVDT displacement transducer.
Dynamic Load Control: 0.1–20 Hz frequency range with sine/square/random waveforms.
Thermal-Mechanical Bath: 37±0.5°C recirculating water system with anti-evaporation design.
High-Resolution Imaging: Built-in 2MP camera system for fretting corrosion analysis.
Safety Suite: Emergency stop, overload clutches, and water leak detection system.
Technical Parameters
| Parameter | Specification |
|---|---|
| Max. Dynamic Load | ±600 N (0.01 N resolution) |
| Frequency Range | 0.1–20 Hz (0.01 Hz increments) |
| Load Ratio (R) | 0.1–10 (adjustable) |
| Displacement Range | ±5 mm (0.001 mm resolution) |
| Water Bath Temperature | 37±0.5°C (PT1000 sensor) |
| Data Sampling Rate | 10 kHz (synchronized across 8 channels) |
| Power Requirements | 220V/110V ±10%, 50/60Hz, 1.200W |
| Dimensions (W×D×H) | 450 × 400 × 600 mm |
| Weight | 55 kg (net) / 65 kg (with water bath) |
| Noise Level | <55 dB (A-weighted) |
Accessories
Dental Implant Fixture Kit:
Adjustable angle clamps (0°–25° pre-set options)
Self-centering abutment adapters (3.0–6.5 mm compatibility)
Thermal-Mechanical Bath:
10L capacity with recirculating pump
Corrosion-resistant titanium interior
FatigueMaster Pro Software:
Automated S-N curve generation and fatigue limit calculation
21 CFR Part 11-compliant audit trail with blockchain timestamping
Remote monitoring via iOS/Android app
Operator Kit:
Calibrated torque wrench set (0.1–10 Nm)
Implant alignment jigs (ISO 14801 compliant)
Calibration Bundle:
NIST-traceable force calibration weights
