Rattle Noise/Sound Detection Tester (for Rattle tester)

Bell Rattle Toy Tester:

Also known as:

Sound-emitting toy tester

Toy test template AB

Anti-choking test device

Simulates children's oral cavity capacity to detect potential choking hazards from toys or accessories.

Compliance Standards & Specifications:

SpecificationElliptical TesterCircular Tester
Standards US: 16CFR 1510 / ASTM F 963 4.6.2
EU: EN71-1998 8.16
China: GB6675-2003 A.5.3
US: 16CFR 1510 / ASTM F 963 4.6.2
EU: EN71-1998 8.16
China: GB6675-2003 A.5.3
Material Aluminum Alloy Aluminum Alloy
Dimensions 80×65×30mm (Ellipse) 72.6×72.6×30mm (Circle)
Weight 320g 320g

Test Procedure & Criteria:

Testing Methodology:

1. Secure the elliptical tester with clamps ensuring vertical alignment

2. Position the toy in the most probable insertion orientation

3. Apply only gravitational force during testing

4. Observe complete penetration depth

5. Repeat for spherical/circular-ended toys using circular tester

Evaluation Criteria:

- Toys shall NOT fully penetrate elliptical tester

- Spherical/circular-ended toys shall NOT fully penetrate circular tester

- Acceptable partial penetration ≤ 50% of total depth

Special Cases:

- For ball-shaped components: Perform 3 consecutive tests

- Record maximum penetration depth for each orientation
