Fire stability tester paper gypsum board

•

Introduction:

The Fire Stability Tester for Paper Gypsum Board is an essential instrument designed to evaluate the fire-resistant properties of gypsum-based boards, a widely utilized material in modern construction for walls, ceilings, and partitions. This tester meticulously assesses the ability of paper-faced gypsum boards to maintain their structural integrity and provide a barrier against fire under controlled high-temperature conditions. By adhering to stringent testing protocols, manufacturers and quality assurance teams can ensure their products meet crucial safety regulations and contribute effectively to minimizing fire hazards in buildings.

This specialized equipment typically employs a controlled heat source, often using liquefied petroleum gas (LPG) burners, to apply a consistent and measurable thermal load to the surface of the gypsum board specimen. The distance between the burner and the board surface is precisely regulated according to relevant testing standards, ensuring uniformity across tests. To simulate real-world conditions where structural elements are often under load during a fire, the tester is also designed to apply a specific weight or load to the gypsum board. This combination of heat exposure and mechanical stress allows for a comprehensive evaluation of the board's fire stability.

Throughout the test, critical parameters such as the surface temperature of the gypsum board, the temperature on the unexposed side, and any signs of structural failure (like cracking, significant deflection, or collapse) are carefully monitored and recorded. The duration for which the gypsum board can withstand the fire exposure and load without succumbing to these failure modes determines its fire stability rating. This rating is crucial for building codes and regulations, which often specify the minimum fire resistance required for different parts of a building to ensure sufficient time for evacuation and fire suppression efforts. The Fire Stability Tester for Paper Gypsum Board is, therefore, indispensable in the construction industry for guaranteeing the safety and reliability of gypsum board as a vital fire-resistant building material.

Technical parameters:

1. combustion temperature :600——850℃

2. gas pressure :2.75±0.49kPa

3. use gas: propane, gas, liquefied gas

4. flow adjustment range :100——1000L/h

5. temperature measuring range :0——1199℃

6. suspension load :0.75——2.5kg

7. power supply, power :220V50Hz120W

8. Net weight :60kg
