ODF Patch Panel P4 Series
DescriptionODF patch panels are designed to provide a high density 19" rack-mountable solution for next generation fiber networks,Website:, it is used as terminal equipemnt of fiber optical cable for fiber patching,fixation,splicing and management.Green Telecom ODF patch panel offers superior optical performance, high stability and high reliability, meet various application requirements in FTTx construction , ODN construction, LAN, Metro network and CATV.Features● Rack-mounted 19" with sliding drawer and front flip panel design● Integrated with splice cassette and cable management elements● Manages large quantities of fiber with high density design● Easy to maintain and extend fibers in the future● Fiber bend radius control more than 40mm● Suitable for the splice of ribbon and bunchy cables● Maximum capacity up to 720 ports● Efficient space for cable management● Cable led out from left or right side of patch panel rear part ● Fully comply with Telcordia GR1209/1221 qualificationsSpecificationODF Patch Panel P4 Parameter Adaptor TypeSC,FC,ST,Duplex SC,Duplex LCCapacity12,24,48,72,96,648,720 fibersBody MaterialCold rolled steel or stainless steelSurface TreatmentPowder coating computer grey colorInstallation MethodStandard 19 inch rack mount Size Dimension(mm)486(W) x275(D)x44(H) for 12F486(W) x275(D)x74(H) for 24F486(W) x275(D)x128(H) for 48F486(W) x275(D)x182(H) for 72F486(W) x275(D)x238(H) for 96FRack Dimension(mm)860(W) x365(D)x2000(H) Rack for 648F860(W) x365(D)x2200(H) Rack for 720FStrengthen Member FixationYesBending Radius(mm)> 40Customization Event①Body Material②Body Color③Fiber Capacity④Pigtail Type⑤Adaptor Type⑥Branding Logo PrintOrdering Information
ODF-P4-XX -XX- XX-- XX- XX-- XX 1 - 2 - 3 - 4 - 5 - 6 1 Body Material2 3 Adaptor4 Capacity5 Pigtail6 Body Color01:Cold Rolled SteelNil:No Adaptor12:12F09B:0.9mm BunchyWT:White02:Stainless SteelSU:SU/UPC24:24F09S:0.9mm SingleGY:Grey SA:SA/UPC48:48F09R:0.9mm Ribbon FU:FC/UPC72:72F20S:2.0mm Single FA:FC/APC 30S:3.0mm Single LU:LC/UPC LA:LC/APC
