High-Precision Cone Calorimeter for Flammability Testing

Whats/App: +86 156 1874 6768

Web: standard-groups.com

Standards

This apparatus conforms to the following international and national standards:

GB/T 16172‑2007 — Determination of heat release rate and total heat release of building materials and products (Cone Calorimeter Method)

ISO 5660‑1 — Heat release, smoke production, and mass loss measurement for building materials (Cone Calorimeter Method, Part 1)

ISO 5660‑2 — Heat release, smoke production, and mass loss measurement (Part 2: Flame spread testing)

ISO 5660‑4 — Heat release and smoke generation test for automotive interior materials

ISO 5660‑5 — Heat release, smoke production, and mass loss measurement: Additional assessment requirements

ASTM E1354 — Cone calorimeter method for heat release rate and visible smoke release

ASTM E2965 — Guidelines for assessing material combustibility using oxygen consumption

Parameters

Parameter	Specification
Dimensions	2135 × 915 × 2810 mm
Weight	650 kg
Mass Balance Range	6000 g, resolution 0.01 g
Gas Analysis	German Siemens analyzer, high precision
Exhaust System	Condensation-type smoke treatment with triple filtration
Material Handling	Sample loading unit with automated placement
Software	Integrated data acquisition and analysis system
Operating Gas	Compressed air
Calibration Gases	Methane, N2. CO2/CO mixed gas
Power Requirement	220V / 380V, 50 Amps
Operating Temperature	10–35°C

Features

Integrated computer and acquisition system: Streamlines data collection and analysis.

Durable stainless steel housing: Ensures long-term stability and corrosion resistance.

Triple filtration system: Effectively cleans exhaust gases and protects sensors.

High-resolution mass balance: Measures sample mass loss accurately with 0.01 g resolution.

High-precision gas analysis: Siemens analyzer provides reliable measurement of combustion gases.

Condensation-type smoke treatment: Efficiently collects and condenses combustion gases.

User-friendly operation: No need to manually remove or insert optical filters during testing.

Robust main filter: Stainless steel housing ensures durability and easy maintenance.

Accessories

Loading unit with automated sample placement

Electric spark ignition system

Condensation and exhaust duct system with triple filtration

Optical smoke measurement system

High-precision mass balance

Gas analysis system (Siemens analyzer)

Data acquisition and integrated software system

Calibration gases: Methane, N2. CO2/CO mixture

Test Procedures

Install the sample on the loading unit and ensure proper positioning.

Connect compressed air and calibration gas supplies.

Set the cone heater to the desired heat flux and ignite the sample using the electric spark system.

Measure mass loss, gas concentration, temperature, and smoke density during combustion.

Data is automatically recorded and processed to calculate heat release rate, effective heat of combustion, and derived parameters.

After testing, safely remove the sample and perform routine cleaning of the exhaust and measurement systems.

Maintenance Information

Clean the cone heater, exhaust ducts, and filters regularly to maintain measurement accuracy.

Calibrate the mass balance, gas analyzers, and optical smoke measurement system periodically.

Inspect the sample loading unit and ignition system before each test.

Ensure the exhaust system and filtration components are unobstructed.

Maintain ambient temperature between 10–35°C and verify gas supply pressures before operation.
