Ultra-High Purity Neon
Product Details
Product Name
Ultra-High Purity Neon
Neon
Purity
Ultra-High Purity Neon: ≥99.9995%
Neon: ≥99.999%
Impurity Content (ppm)
| Impurity | Ultra-High Purity Neon | Neon |
|---|---|---|
| Hydrogen (H₂) | ≤1 | ≤2 |
| Helium (He) | ≤5 | ≤6 |
| Oxygen (O₂) + Argon (Ar) | ≤0.5 | ≤1 |
| Nitrogen (N₂) | ≤1 | ≤2 |
| Hydrocarbons (CH₄) | ≤0.5 | ≤1 |
| Water (H₂O) | ≤0.8 | ≤1.5 |
| Total Impurity Content | ≤9.5 | ≤13.5 |
Packaging
Filled in 40L steel cylinders, and also available in smaller cylinders of 8-10L upon customer request.
Applications
Recommended for industrial use, used for filling electronic tubes, neon lights, sodium vapor lamps, and as a liquefied cryogenic source, etc.
Physical and Chemical Properties
CAS Number: 7440-01-9.
Physical and Chemical Characteristics: Colorless and odorless inert gas. Slightly soluble in water. Melting point (℃): -248.7; Boiling point (℃): -245.9; Relative density (water=1): 0.07 (-252℃); Relative density (air=1): 0.07; Saturation vapor pressure (kPa): 13.33 (-257.9℃); Flash point (℃): No data; Combustion heat (kJ/mol): 241; Critical temperature (℃): -240; Critical pressure (MPa): 1.30; Upper Explosion Limit (v%): 75; Lower Explosion Limit (v%): 4.1; Ignition temperature (℃): 500–571.
Combustion and Explosion Hazards: Non-flammable. Under high heat, the pressure inside the container may increase, posing a risk of rupture and explosion.
Firefighting Methods: Non-flammable. Remove containers from the fire area if possible. Spray water to keep the containers cool until the fire is out. Evacuate people to the upwind side and isolate the contaminated area. Emergency personnel should wear self-contained positive pressure breathing apparatus and general work clothes. Cut off the leak source if possible. Ensure adequate ventilation to disperse the gas. Handle the leaking container properly, repair and inspect before reuse.
Health Hazards: Inert gas, at high concentrations, can reduce oxygen partial pressure in the air, posing a risk of asphyxiation. Symptoms include increased breathing rate, lack of concentration, ataxia, followed by fatigue, restlessness, nausea, vomiting, coma, convulsions, and potentially death.
First Aid Measures: Inhalation: Quickly move to a fresh air area. Keep the airway clear. If breathing is difficult, administer oxygen. If breathing stops, perform artificial respiration immediately. If breathing and heartbeat stop, perform artificial respiration and external chest compressions immediately.
