Fabric Anti-Electromagnetic Radiation Performance Tester - lab instrument
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Email: serving@qinsun-lab。com
Standards
GB/T23326. GB/T25471. ASTM D4935. SJ2054
Application
It is used for testing the electromagnetic shielding effectiveness of electromagnetic shielding materials such as textiles, plastic sheets, metal foils, surface coatings or platings of non-conductive materials, metal meshes, conductive films, conductive glasses, and conductive medium plates (using the coaxial method).
Features
1. The instrument adopts the coaxial test method, with good transmission characteristics and high testing accuracy.
2. It can perform full-frequency scanning, list scanning, and point-frequency measurement.
3. It uses the internationally preferred coaxial test method to measure the shielding effectiveness of materials, with good transmission characteristics and improved testing accuracy.
4. The instrument automatically controls the emission and reception of signals, automatically collects and processes data, displays curves on the LCD screen, and prints test data with a micro printer, which is easy to operate.
5. The evaluation of the absorption and reflection performance of planar materials against electromagnetic waves can be obtained by calculating the measured parameters.
6. RS232 data interface, with computer software for curve display, data analysis, and storage.
7. It provides a USB interface and supports mobile data storage with a USB flash drive.
Technical Parameters
1. Signal Source:
1.1 Test frequency range: 300 KHz - 3000 MHz
1.2 Frequency stability: ≤ ±5×10⁻⁶
1.3 Frequency resolution: 1 Hz
1.4 Signal purity: ≤ -65dBc/Hz (at 10 KHz offset)
1.5 Output level: -45dBm - +10 dBm
1.6 Level accuracy: ≤ ±1.5dB (25°C ± 5°C, -45dBm - +5 dBm)
1.7 Harmonic suppression ratio: ≥30dB (1MHz - 3000MHz), ≥25dB (300KHz - 1MHz)
1.8 Directivity: ≥50dB (after vector calibration)
1.9 Power scanning: -8dBm - +5dBm
1.10 System impedance: 50 ohms
