High-Speed Reciprocating Friction and Wear Tester (Type 02)
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The High-Speed Reciprocating Friction and Wear Tester (Type 02) is designed to evaluate the friction and wear performance of materials and surface coatings. The device uses automatic loading to simulate point, line, and surface contact forms in reciprocating motion. You can test friction force, coefficient of friction, and other tribological parameters under different loads, frequencies, and temperatures. Lubricated tests are also supported. The tester is controlled via an industrial computer and dedicated software, allowing real-time monitoring, data storage, and report generation.
Applications
You can use this tester to:
Evaluate the friction and wear performance of various materials and coatings
Simulate friction under different loads, frequencies, and temperatures
Perform reciprocating friction tests with point, line, and surface contacts
Conduct tests under lubricated conditions
Support material research, product testing, and quality control
Standards
ASTM G99 – Standard Test Method for Wear Testing
ASTM G133 – High-Temperature Friction and Wear Test Method
ISO 20808 – Solid Material Friction and Wear Test
GB/T 3147 – Determination of Friction Material Wear Performance
Technical Specifications
| Parameter | Specification |
|---|---|
| Maximum Reciprocating Frequency | 20 Hz (continuously adjustable), 30 Hz (optional) |
| Maximum Stroke | 40 mm |
| Maximum Friction Force | 100 N |
| Maximum Load | 200 N |
| Friction Pair Types | Pin-on-disk, Ball-on-disk, Cylinder-on-block |
| Test Duration Control | 1 s – 9999 h |
| Lifting Height | 25 mm |
| High-Temperature Module (Optional) | Room temperature – 600℃ |
Features
High-Frequency Testing: Reciprocating frequency up to 20 Hz, supporting high-speed wear experiments
Large Stroke Range: Maximum stroke 40 mm, suitable for various friction pairs and test conditions
High-Precision Measurement: Friction force up to 100 N, load up to 200 N, ensuring accurate testing
Multiple Friction Pairs: Supports pin-on-disk, ball-on-disk, cylinder-on-block configurations
Temperature Control: Optional high-temperature module allows testing up to 600℃
Full Automation: Controlled via industrial computer and software, with automated data recording and report generation
Safety Features: Equipped with overload shutdown and alarm functions to protect you and the equipment
