Continuous Load Scratch Resistance Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
Scratch resistance testing of mobile and tablet display screens
Scratch resistance evaluation of functional and decorative films
Scratch durability assessment of wallpapers and surface coverings
Adhesion strength testing of coatings under progressive load
Surface hardness and smoothness characterization
Typical test samples include:
Glass and coated display panels
Protective and decorative films
Wallpaper and laminated surfaces
Painted, varnished, or coated substrates
Standards
ISO DIS 12137-2 (Plastics — Determination of Scratch Properties)
JIS K 5600 (Testing Methods for Paints)
Parameters
| Parameter | Specification |
|---|---|
| Sliding speed | 600 mm/min (return speed: 1200 mm/min) |
| Drive motor | Reversible motor |
| Drive mechanism | Rack and pinion transmission |
| Sliding distance | 100 mm |
| Vertical load | Continuous load: 0–50 g, 0–100 g, 0–200 g |
| Fixed load: 200 g | |
| Safety system | Overload protection, high-frequency noise suppression circuit |
| Overall dimensions | Main unit: W535 mm × D225 mm × H340 mm |
Features
Multiple test functions integrated into a single system
Scratch resistance testing in accordance with ISO DIS 12137-2. with scratch size evaluated by microscopic observation
Pencil hardness–type testing based on JIS K 5600. using a 45° inclined pencil to compare surface hardness
Surface smoothness measurement by recording sliding resistance of a flat fixture to calculate static and dynamic friction
Optional friction and wear analysis software enables quantitative evaluation of scratch resistance based on measured resistance
Accurate determination of critical loads corresponding to surface indentation and cracking through resistance variation analysis
