Male Side Impact Dummy RE Type Manufacturer
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Male Side Impact Dummy (RE Type) is a high-fidelity side impact test dummy designed based on 50th percentile adult male anthropometric data. It is used to simulate biomechanical responses of occupants during vehicle side collisions, accurately representing chest, pelvis, and lower limb acceleration, load, and displacement. The dummy features an enhanced rib structure with a rib extension mechanism, enabling realistic interaction with seats and door panels. It is suitable for regulatory testing, NCAP evaluation, and vehicle passive safety development.
Standards
(1) GB/T 11551 – Protection of occupants in frontal and side collisions
(2) GB 14166 – Motor vehicle seat belts and restraint systems
(3) FMVSS 214 – Side impact protection
(4) UNECE R95 – Lateral collision protection
(5) UNECE R135 – Pole side impact
(6) SAE J1727 – Side impact dummy performance specification
(7) ISO 15830 – Road vehicles – Side impact dummy – Calibration
(8) Euro NCAP – Side impact test protocol
Features
(1) Designed based on 50th percentile adult male anthropometry for high biofidelity;
(2) Enhanced rib structure with rib extension mechanism for realistic chest lateral compression and displacement;
(3) Accurate interaction with seats and door panels;
(4) Supports multi-channel force, acceleration, and displacement measurement;
(5) Stable structure suitable for regulatory and high-repetition tests;
(6) Compatible with multiple international side impact regulations and NCAP protocols.
Accessories
(1) High-precision accelerometer set
(2) Load cell and displacement sensor modules
(3) Rib extension mechanism
(4) Replaceable limb modules (arms, legs, torso)
(5) Data acquisition interfaces and calibration tools
(6) Dedicated transport frame and mounting base
Parameters
Dimensional Data
| No. | Item | Dimension (mm) |
|---|---|---|
| 1 | Sitting height | 909 ±9 |
| 2 | Seat to shoulder | 565 ±7 |
| 3 | Seat to bottom of thorax box | 351 ±5 |
| 4 | Seat to hip joint (bolt center) | 100 ±3 |
| 5 | Foot to seat height (sitting) | 442 ±9 |
| 6 | Head width | 155 ±3 |
| 7 | Shoulder breadth | 470 ±9 |
| 8 | Chest width | 327 ±5 |
| 9 | Abdomen width | 280 ±7 |
| 10 | Pelvis width | 366 ±7 |
| 11 | Head depth | 201 ±5 |
| 12 | Chest depth | 267 ±5 |
| 13 | Abdomen depth | 199 ±5 |
| 14 | Pelvis depth | 240 ±5 |
| 15 | Rear pelvis to hip joint (bolt center) | 155 ±5 |
| 16 | Rear pelvis to front knee | 606 ±9 |
Mass Distribution
| Component | Mass (kg) |
|---|---|
| Head | 4 ±0.05 |
| Neck | 1 ±0.05 |
| Thorax | 22.4 ±1 |
| Left arm | 1.3 ±0.1 |
| Right arm | 1.3 ±0.1 |
| Abdomen | 5 ±0.25 |
| Pelvis | 12 ±0.6 |
| Left leg | 12.7 ±0.6 |
| Right leg | 12.7 ±0.6 |
| Total | 72.4 ±1.2 |
Sensor Configuration
| Location | Sensor Type | Channels |
|---|---|---|
| Head | Accelerometer | 3×1 |
| Head | Gyroscope | 3×1 |
| Upper Neck | 6-channel load cell | 1×6 |
| Lower Neck | 6-channel load cell | 1×6 |
| Shoulder | 3-channel load cell | 1×3 |
| Thorax | Tilt sensor | 1×2 |
| Torso | 4-channel load cell | 1×4 |
| Thoracic T1 | Accelerometer | 1×3 |
| Thoracic T12 | Accelerometer | 3×1 |
| Ribs | Accelerometer | 3×1 |
| Ribs | Linear potentiometer | 3×1 |
| Thoracic T12 | 4-channel load cell | 1×4 |
| Abdomen | Single-channel load cell | 3×1 |
| Lower lumbar | 3-channel load cell | 1×3 |
| Pelvis | Tilt sensor | 1×2 |
| Pubis | Single-channel load cell | 1×1 |
| Sacrum | Accelerometer | 3×1 |
| Thigh | 6-channel load cell | 1×6 |
