Electrolyte wettability test system
Standard
- ASTM D724-98: Standard Test Method for Surface Wettability of Paper (Angle-of-Repose Method Adapted)
- ISO 8296: Plastics – Determination of Wettability of Film and Sheeting
- DIN 53901: Testing of Coating Materials – Determination of Contact Angle
- RoHS Compliance(Restriction of Hazardous Substances)
- CE Certification(Conformité Européenne)
Product Advantages
- Dynamic Contact Angle Measurement
- 0.1° Angular Resolution: Captures rapid electrolyte absorption kinetics.
- Multi-Fluid Compatibility: Tests aqueous, organic, and ionic liquid electrolytes.
- High-Speed Imaging
- 1,000 FPS Camera: Visualizes wetting front propagation in real-time.
- Auto-Focus Microscopy: Maintains clarity during electrolyte evaporation.
- Environmental Control
- Glovebox Integration: Oxygen/moisture levels <0.1 ppm for sensitive chemistries.
- Temperature Stage: -30°C to 150°C with ±0.05°C stability.
- Data Intelligence
- AI-Powered Analysis: Automatically calculates contact angle hysteresis and spreading coefficient.
- 3D Wetting Maps: Reconstructs electrolyte penetration pathways in porous electrodes.
- User-Centric Design
- 15.6” 4K Touchscreen: Multi-touch gestures for zoom/pan on live video feeds.
- Voice-Activated Controls: Hands-free operation during solvent handling.
Product Features
- Non-Destructive Testing (NDT): Preserves sample integrity with <1 μN force application.
- Automated Liquid Dispensing: Programmable micropipette (0.1–10 μL precision).
- Multi-Angle Illumination: LED ring light with 16-bit intensity control.
- Laser Height Gauge: Ensures consistent sample positioning (±1 μm accuracy).
- Emergency Solvent Drain: Anti-spill system with gravity-activated siphon.
Technical Parameters
| Parameter | Specification |
|---|---|
| Contact Angle Range | 0°–180° (dynamic measurement) |
| Accuracy | ±0.5° (contact angle), ±0.1 μL (dispensing) |
| Imaging Resolution | 4096 × 2160 pixels (8.3 MP) |
| Frame Rate | 1,000 FPS (max), adjustable down to 1 FPS |
| Data Storage | 2TB SSD (expandable via USB 3.2) |
| Power Supply | 100-240V AC, 50/60Hz (universal adapter) |
| Dimensions | 600mm (W) × 550mm (D) × 700mm (H) |
| Weight | 120 kg (net) / 150 kg (gross) |
Accessories Included
- Testing Kit:
- Platinum-iridium substrate holders (10mm/20mm/50mm diameters).
- Disposable micropipette tips (1,000 pack).
- Software Suite:
- License key forWettabilityAI Pro(Windows/macOS).
- 1-year free access to cloud-based image recognition API.
- Calibration & Safety:
- NIST-traceable contact angle standard (30°, 90°, 150°).
- Chemical-resistant gloves (Class 00, 3 pairs).
- Environmental Control:
- Gas purification cartridge (99.999% inert atmosphere).
- Humidity sensor with data logging.
- Documentation:
- Multilingual quick-start guide (printed + digital).
- Compliance certificates for ASTM/ISO/CE standards.
