PV Backsheet Abrasion Tester
Standard
- IEC 61730-2: Photovoltaic (PV) Module Safety Qualification – Requirements for Testing
- UL 1703: Flat-Plate Photovoltaic Modules and Panels
- CE Certification(Conformité Européenne)
Product Advantages
- IEC/UL Compliance
- 150±30 mm/s Scratch Speed: Replicates 10+ years of abrasion per IEC 61730-2.
- 360° Traction Direction: Tests backsheet resistance from all angles.
- Precision Engineering
- 0.1 mm/s Speed Resolution: Ensures repeatable abrasion cycles.
- Load-Cell Feedback: Auto-adjusts force for consistent 10N cutting pressure.
- Durability
- Aircraft-Grade Aluminum Table: Resists warping under 50 kg max load.
- Corrosion-Resistant Pulleys: Stainless steel construction for humid environments.
- Safety First
- Emergency Shutoff: Dual redundant safety circuits with E-stop button.
- Overload Protection: Auto-pause at 50N force to prevent sample damage.
- User-Centric Design
- 7” Touchscreen HMI: Preloaded IEC/UL test sequences with auto-hold functions.
- Voice-Guided Setup: Step-by-step audio prompts for operators.
Product Features
- Modular Test Table: 1.4m × 0.65m aluminum alloy surface with quick-clamp fixtures.
- Motorized Traction System: 0–300 mm/s adjustable speed with forward/reverse control.
- Dynamic Force Control: 1–50N adjustable load with real-time force graphing.
- Self-Calibrating System: Auto-tare and linearity checks before each test.
- Rust-Resistant Frame: 304 stainless steel construction with epoxy coating.
Technical Parameters
| Parameter | Specification |
|---|---|
| Tabletop Size | 1,400mm (W) × 650mm (D) |
| Scratch Speed | 120–180 mm/s (adjustable) |
| Traction Force | 1–50N (0.1N resolution) |
| Speed Accuracy | ±2% of setpoint |
| Power Supply | 220V AC, 50/60Hz (single-phase) |
| Dimensions | 1,600mm (W) × 800mm (D) × 1,200mm (H) |
| Weight | 120 kg (net) |
Accessories Included
- Testing Kit:
- 5x Diamond Indenters (10–50 μm tip radius).
- 10x Backsheet Sample Clamps (adjustable for 1–10 mm thickness).
- Consumables:
- 1x Calibration Grade Abrasion Paper (100 grit).
- 5x Replacement Cutting Blades.
- Documentation:
- Multilingual Quick-Start Guide (printed + digital).
- Compliance Certificates for IEC/UL Standards.
- Safety Gear:
- 2x Cut-Resistant Gloves (EN 388 Level 5).
- 1x Eye Protection Shield.
- Software Suite:
- License key forScratchTest Pro(Windows/macOS).
- 1-year free access to cloud-based abrasion analysis tools.
