Floor Material Burning Performance Tester，Flooring Radiant Panel Tester by ISO 9239-1
Thefloor coverings flammability testeris used to tester a variety of flooring materials, such as: textile carpets, cork, wood, rubber and plastic flooring and floor spray materials. The results can reflect the combustion properties of the floor material (including the substrate), which is used in the test combustion chamber to ignite the floor material placed horizontally and exposed to the tilted thermal radiation field with a small flame. It can be used to evaluate the material flame Communication ability.
Standards
ASTM E648-15 Standard test method for critical radiant flux of floor-covering systems using radiant heat energy source
BS EN ISO Reaction to fire test for flooring-Part1: Determination of the burningbehavior using a radiant heat source
GB/T 11785-2005 Determination of Combustion Performance -Floor material radiation heat source method
ISO 9239-1: Flooring fire reaction test- Part 1: Combustion performance of flooring materials tested by radiant heat
ASTM E 648: Critical Radiant Flux of Floor standard test - covering system uses radiant heat energy
ASTM E 970: Using a Radiant Heat Energy Source, test insulation floorinsulation insulation standard test for Critical Radiant Flux using a radiant heat energy.
NFPA 253: Standard Test Method for using radiant heat energy, test plates overlay system Critical Radiant Flux
Technical Parameters
| Items | Parameters |
| Radiant heat source | Radiation surface size is (300 × 450) mm ± 10mm, the radiation plate can withstand the high temperature of 900 ℃ |
| Specimen fixture | It is made of refractory and (2.0 ± 0.1) mm L-shaped stainless steel. The size of the exposed surface of the specimen is (200 ± 3) mm × (1015 ± 10) mm |
| Igniter | Stainless steel igniter is used for ignition of the specimen. The center line on the average distribution of 19 diameter 0.7mm a radial hole, the center line of 60 degrees on the average distribution of 16 diameter 0.7mm radial hole |
| Propane rotor flow | Propane gas flow can control at (0.026 ± 0.002) L / s, to ensure that the ignition flame height is (60 ~ 120) mm |
| Power supply | AC380V three-phase five-wire system |
| Smoke removal rate | 2.5 ± 0.2 m / s |
| Smoke capacity | 39 ~ 85 m3/ min |
| Items | Parameters |
| The heat balloon anemometer measures the flow rate of the exhaust channel with an accuracy is ± 0.1 m / s | |
| Water-cooled heat flux meter | Heat flux meter Measuring range: 0 ~ 15Kw / m² |
| Heat flux range accuracy | ± 0.2Kw / m2 |
| Heat flux accuracy | <± 3% |
| Temperature sensor | K-type stainless steel installed two thermocouple, diameter is 3.2 mm. Respectively installed in the floor material radiation test box and the flue from the top of the box flue (150 ± 2) mm |
| Radiation pyrometer | The test range is (480 ~ 530) ℃ (black body temperature). The accuracy is ± 0.5 ℃. It is about 1.4m away from the radiation plate. The sensitivity of radiation pyrometer is constant in the wavelength of 1μm to 9μm range |
Features
The main components are imported, which is safe and reliable, long service life;
Gas pipeline layout is reasonable, equipped with gas leakage and tempering device. The instrument automatically closes at the inlet of gas leakage, and alarm;
Radiant plate temperature can be automatically adjusted.
Propane gas supply is equipped with imported mass flow controller. The air output is equipped with a separate blower. Automatic adjustment of the frequency without manual;
Normal test, the flame spread distance can be recorded through the foot switch, without the need to manually click the mouse to operate the computer;
Instrument with industrial one machine, is easy to operate and reliable;
The instrument adopts advanced control software developed by VB language. Centralized control acquisition and processing data analysis;
在线联系供应商
Other supplier products
 |
Compression Fatigue Testing Machine | Standard YY/T 0959-2014 (China): Specifies compression fatigue testing protocols for intervertebral fusion devices, including load ratios, frequen... |
 |
Safety Footwear Compression Puncture Tester | Test purpose Measure the compression resistance of the shoe head cover and the puncture resistance of the steel plate to prevent the operator from... |
 |
Lithium battery explosion test chamber丨Lithium battery explosion chamber | Lithium battery combustion and explosion experiment chamber is mainly used for thermal runaway combustion and even explosion experiments of lithium... |
 |
Pressure Transmission Flow Meter Test Instrument | The Pressure Transmission and Flow Tester is widely used in multiple fields and is mainly used to test the pressure transmission and flow performan... |
 |
Halogen Acid Gas Content Testing Machine，IEC 60754 | Description: This tester is used to test the acidity of the gas that released during combustion from cable or optical cable components material; T... |
