Liquid Sliding Penetration Comprehensive Performance Tester
G373 Liquid penetrating and strike-through comprehensive performance tester - Penetrability test of diapers G373 Liquid penetrating and strike-through comprehensive performance tester, It is suitable for determining penetrating quality of diapers, including amount of strike-through, back-seepage and penetration, which can also be used to determine the liquid penetrating properties of hygienic non-woven and the efficiency of liquid permeation. The technical principle is that a certain amount of liquid is poured on the surface of the sample to measure its penetration and permeability to the liquid. G373 Liquid penetrating and strike-through comprehensive performance tester 1.A funnel with solenoid valve controls the liquid penetrate test, and the diaper strike-through test can be carried out by funnel with valves to simulate the daily use of the diaper. 2.The special mechanical mechanism makes the sample holder easy to meet the test of multiple tests, and the angle control of the sample holder is convenient, it is very easy to meet the requirements of the test to ensure the reproducibility of the test. Standards compliant QB/T 2493-2000 Diapers (including diaper care/pads) FZ/T 60017-1993 Hygienic thin non-woven fabric liquid permeability test method Instrument features: 1. A funnel with a solenoid valve is used to control the liquid penetration test, and a funnel with a valve is used to perform the diaper penetration test to simulate the daily use of diapers; 2. A special mechanical mechanism is used to make the sample rack convenient for multiple tests, and the angle of the sample rack is easy to control, which is very easy to meet the test requirements and ensure the reproducibility of the test; 3. The control system with sensors ensures real-time capture of the liquid data that is passed through; 4. The designed data processing software can timely transmit the data to the computer for data analysis and generate curves, which is convenient for technicians to perform various data analyses in order to improve the performance of the product; 5. The automatic control system makes the entire test process simple and convenient. Field Application G373 Liquid penetrating and strike-through comprehensive performance tester, The penetrating quality of diapers, including the amount of strike-through, back-seepage and penetration, which can also be used to determine the liquid penetrating performance of hygienic non-woven. It is applicable to the performance verification of new products, quality control of the production department, and the of material properties for the third-party testing organization, the product performance verification laboratory, and the quality and technical supervisiondepartment, etc. Technical Parameters Angle：(30±2)° Penetrating efficiency: time spent penetrating 50mL of liquid Weight: ￠100mm, weight (1.2±0.002) kg (it can produce pressure of 1.5kPa) Weight :30kg Funnel flow：80mL/6s Power supply:220V 50Hz Pressing block pressurization time：1min Appearance size:500mm×600mm×500mm Strike-through penetrating time：10min
