Surgical Mask Flame Retardant Test machine
Flame-retardant tester for surgical mask, In case of the mask is accidentally exposed to flame, its flame-retardant performance is directly related to the safety of medical personnel. The flame-retardancy of mask is one of the important physical indicators for measuring the quality of surgical masks.
Standards:
GB 19083-2010 Technical Requirements for Medical Protective Masks, 5.5 Performances of Synthetic Blood Penetration and Barrier
YY 0469-2011 Technical Requirements for Medical Surgical Masks, Blood Penetration Test Device
GB 2626-2006 Respiratory protective equipment,Filtered particulate respirator,Flammability
BS EN136-1998 Respiratory protection equipment Full Face Mask Requirements test sign
Major Features
Touch-tone + Counting module control
The digital display counter can preset the 1-99999s time test and automatically stops after the test is completed.
Emulational human head model
The mask clamp is a metal human head model that can fully simulate the actual use of the mask.
High degree of equipment automation
The instrument automatically records the burning time and flame-retardant time with digital display, and equipped with flame temperature measuring probe, flame temperature display, with characteristic of automatic ignition and adjustable flame height.
Application:
flame-retardant tester for surgical mask , It is mainly used to test the burning performance of surgical masks after contact with flame at a certain line speed, which is a special test instrument for flame-retardant performance of surgical masks.
It is applicable to the performance verification of new products, quality control of the production department, and the of material properties for the third-party testing organization, the product performance verification laboratory, and the quality and technical supervisiondepartment, etc.
Technical Parameters
|
Test mode: automatic |
Burner timing:0~9999.9₮ |
|
Linear velocity of head model automatic movement: (60±5) mm/s |
Distance between the top of the burner and the lowest point of the mask: (20±2) mm, The flame is at a height of (20±2) mm from the top of the burner |
|
Flame height:40±4mm |
Temperature: (800 ±50) C |
|
Temperature sensor: thermocouple detection |
Weight:65k |
|
Burner height adjustment range:30mm |
Power supply:220V 5Hz |
|
Wall thickness of metal head model: 2~3mm |
Physical dimension:810mm* 510 mm* 870 mmBurner timing:0~9999.9₮ |
|
flame resistant and resistance to burning |
