Internal shoe size tester | In-side Shoe Gauge Measurement Tool
Product Introduction
While external shoe size markings provide a general guide, the actual space inside a shoe dictates how it will fit a foot. The internal shape and dimensions are influenced by the last used, construction methods, and materials. An Internal Shoe Size Tester provides an objective way to measure the usable volume, primarily the length from the heel area to the furthest point in the toe box.
The tester typically utilizes a probe mechanism designed to be inserted into the shoe. This probe can extend and adapt to reach the extreme internal boundaries of the shoe's length. The instrument then measures the distance between a defined point in the heel area and the furthest point in the toe area accessible to the foot. Some testers use a simple mechanical probe with a graduated scale, while more advanced versions employ digital sensors or encoding systems for greater accuracy and ease of reading. Sophisticated testers might even use multiple probes or scanning technology to measure internal width, height, and overall volume.
Standard
ISO 9407International standard that outlines theprocedure for determining the water vapour resistanceof textiles
SATRA TM362-2008
Product Advantage
- Provides accurate and objective measurement of the actual space available for the foot inside a shoe.
- Essential for ensuring consistent sizing and comfortable fit of footwear.
- Helps identify variations in internal sizing due to manufacturing processes or materials.
- Allows for direct comparison of internal sizing across different shoe styles and manufacturers.
- Useful for quality control in shoe production and for improving last design.
- Aids in selecting the correct shoe size for individual feet.
Technical Parameters
| Test speed | 33+3 times/min |
| Test cycle | 12.000 times |
| Static load | Maximum force 750 N |
| Test shoe size | Sizes 25-45 (Standard size 42 sneakers) |
| Friction interface | Cement board |
| Control method | Touch screen |
| Dimensions (WxDxH) | 246 cm x 100 cm x 171 cm |
|
Power supply |
14V AC 220V 50Hz (depending on country or specification) |
