CWW-N150 Window Wall
Glass wall with windowsystem CWW-N15 is similar to unitized curtain wall system, but are generally less sophisticated. These glass window wall systemsare common on small and medium sized buildings. Like curtain walls, window glass wallpanels are largely prefabricated off-site (commonly in China) and shipped to site. They are normally installed sequentially, but installation can potentially take place over a number of floor at once. Generally window wall panels are installed between each single floor(it is supported by the slab below and above), and more flexible than unitized curtain wall.
Overview of CWW-N150 Window Wall
|
System： |
Window Wall(Non Thermal Break) |
|
Model No.: |
CWW-N150 |
|
Material: |
Aluminum Alloy/Glass/Aluminum Sheet/Aluminum Composite Panel/Galvanized Sheet |
|
Glass Type: |
Tempered/Float/Laminated/DGU/Ceramic Fritted/LowE/Tinted/Reflective/Heat Soak |
|
Cooperated Glass Brand: |
Vitro(Formerly PPG)/Pilkington/Xinyi(SYG)/Yaopi(SYP)/Fuyao/Southglass(SG)/Kibing/CNG/TaiwanGlass |
|
Surface Treatment: |
Powder Coating/PVDF/Anodized/Electrophoresis/Wooden Grain |
|
Profile Brand: |
6063-T5/6063-T6 |
|
Themral Profile: |
Non-Thermal Break |
|
Standards: |
In Complianca With ASTM/AS/NZS/AAMA/NFRC/EN/BSI/ISO |
|
Application: |
Residential Apartment,Villa/Commercial Hotel,Mall,Office,Public Organization |
|
System Customziation： |
Available |
Data of CWW-N150 Window Wall
Testing Data of CWW-N150 Window Wall
|
Test |
Pressure |
Results |
|
Preloading(Clause 8.2.2 of AS/NZS4284:2008） |
+2.58kpa |
No separation, plastic deformations or deleterious was observed |
|
-2.58kpa |
||
|
Preliminary Water Penetration Test under Static Pressure (Clause 8.2.3 of AS/NZS 4284:2008) |
+774kPa |
No water leakage was observed. |
|
Preliminary Water Penetration Test under Cyclic Pressure (Clause 8.2.3 of AS/NZS 4284:2008) |
(Pa) |
No water leakage was observed. |
|
(Pa) |
||
|
(Pa) |
||
|
Structural Test at Serviceability Limit State Wind Pressure (Wsls)(Clause 8.3 of AS/NZS 4284:2008) |
+2.58kpa |
During the structural test at SLS wind pressure, the deflections of all related members were within the allowable deflection limits. |
|
-2.58kpa |
||
|
Operating force test (AS 2047-2014) |
-- |
The operating force was within the allowable value. |
|
Air Infiltration Test (Clause 8.4 of AS/NZS 4284:2008) |
+/-150Pa |
The rate of air leakage of the specimen was within the allowable values. |
|
Water Penetration Test under Static Water Penetration Test under Static 4284:2008) |
+774Pa |
No water leakage was observed. |
|
Water Penetration Test under Cyclic Pressure (Clause 8.6 of AS/NZS 4284:2008) |
(Pa) |
No water leakage was observed. |
|
(Pa) |
||
|
(Pa) |
||
|
Structural ProofTest at Ultimate Limit State Wind Pressure (Wuls) (Clause 8.8 of AS/NZS 4284:2008) |
+4.00kpa |
No collapse of the test specimen was observed under the specified pressure. |
|
-4.00kpa |
Thermal Data of CWW-N150 Window Wall
|
NFRC procedures |
NFRC100SB, NFRC200-2010 and NFRC500-2010 |
|
Software tools: |
THERM 7.4.3.0 and WINDOW 7.4.6.0 |
|
Configuration |
6mm LB13-45#2HS+12AR+6mm Clear HST |
|
Panel Dimension |
1700mm Wide x 2750mm High |
|
Frame |
Painted Aluminum |
|
Panel U-value |
|
|
Visible Light Transmission |
|
|
Condensation Resistant |
Frame Data of CWW-N150 Window Wall
|
Parts Location |
Frame Area/m2 |
Edge Area/m2 |
U-Value(Frame)W/m2k |
U-Value(Edge)W/m2k |
|
Left Header |
||||
|
Left Jamb |
||||
|
Right Header |
||||
|
Mullion |
||||
|
Right Jamb |
||||
|
Left sill |
||||
|
Right sill |
Glass Data of CWW-N150 Window Wall
|
Glass Data: 6mm LB13-45#2HS+12AR+6mm Clear HST |
|||||||
|
Visible Light |
SHGC |
SC |
NFRC U-valueW/m3k(Argon) |
STC |
|||
|
T% |
R-out% |
R-in% |
Winter |
Summer |
|||
|
40 |
20 |
13 |
36 |
||||
Benefit of CWW-N150 Window Wall
Flexible for different buildings
Reduction of installation difficulty
Cost efficient
Shorter project schedule
A expanded view for daily routine
Stable themral performance
Minimum after sales service & maintaining
Increased comfort level
Configuration of CWW-N150 Window Wall
Recommended CAS Facade Products
Our products are designed to snap together perfectly, organically or with the help of couplers. This ensures a streamline design throughout your project. Below is a list of compatible products.
As one of facade engineering firms, we can offer sorts of related products for sale, if you have needs, please contact us.
