Box Compression Tester

Standard operating mode:

1.Carton strength test: can measure the maximum pressure resistance and displacement of the box;

2. Carton setting test: the overall performance of the box can be detected according to the set pressure and displacement;

3 carton stacking test: according to the requirements of the national standard, the stacking test can be carried out for a specified time.

Reference standard:

1. Design standard :GB/T 4857.4-92; GB/T 4857.3-92

2. Test standard :GB/T4857.4; GB/T4857.16;IS02872; ASTM D642

3. Manufacturing standard :GB/T16491; TAPPI-T804; JIS-Z0212

Product Advantages:

Evaluates Critical Packaging Strength: Directly measures compression and stacking strength, key properties for preventing damage during storage and transport.

Multiple Test Modes: Offers distinct operating modes (strength, setting, stacking) to cover various evaluation needs according to standards.

Standard Compliant: Designed to meet numerous national and international packaging testing standards.

High Accuracy: Provides accurate measurement of force and displacement with specified precision.

Supports Design Optimization: Provides quantitative data essential for improving carton design for enhanced stacking performance and material efficiency.

Versatile Application: Applicable to a wide range of carton sizes and types.

Technical parameter:

Force range: 5000kg

Effective force measurement range: 0.2%-100%FS

Force value accuracy: 0.3%

Displacement stroke: 1500mm

Displacement accuracy: 0.5%

Displacement speed range: 1-300mm/min

Pressure plate size: 1800*1800mm

Machine size: about 2550*1800*1880mm(length, width and height)

Machine weight: about 850kg

Power supply: AC 220V 3Kw
