abrasion tester for perforated leather materials
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
This single-station tester performs abrasion (fiber fluff) tests in compliance with Toyota Specification TIS 01208-00F21. simulating real-world wear caused by repeated contact and friction.
It is widely used in automotive material research and quality control to ensure that leather surfaces maintain their appearance and texture over extended use.
Technical Specifications
| Item | Specification |
|---|---|
| Test Type | Single-station abrasion (fiber fluff) test |
| Test Material | Perforated automotive leather |
| Cycle Speed | 70 cycles per minute (adjustable) |
| Operating Stroke | 20 mm |
| Sample Table | Polished stainless steel oscillating table, with double-stick tape attachment |
| Sample Disc | 95 mm diameter aluminum disc, 0.5 kg weight (removable for weight verification) |
| Retaining System | Overhead pass-through sample disc retaining system |
| Counter System | Programmable cycle counter with automatic stop |
| Construction | Precision aluminum and stainless-steel mechanical components |
| Finish | Durable powder coat and anodized finish |
| Power Supply | To be specified at time of order |
Test Procedures
Cut leather samples according to test requirements.
Fix the sample flat on the polished stainless-steel table using double-sided adhesive tape.
Install and check the aluminum sample disc position.
Set test speed and cycle count according to the relevant standard.
Start the device and observe operation to ensure smooth reciprocating motion.
The machine automatically stops when the set cycles are completed.
Remove the sample and evaluate surface abrasion and fiber fluffing.
Record results and compile experimental data.
Maintenance Information
Ensure the sample disc and test table are clean before and after use.
Replace worn brushes or abrasive media regularly.
Inspect mechanical components for wear or loosening.
Calibrate cycle counter and verify sample disc weight periodically.
Store in a dry, clean environment to maintain device longevity.
