Guarded hot plate thermal testing equipment
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
Measurement of thermal conductivity and thermal resistance of metals, polymers, composites, and pastes.
Characterization of thermal performance for materials in aerospace, electronics, automotive, and industrial applications.
Determination of steady-state heat transfer for heterogeneous or non-uniform materials.
Applicable for quality control, material research, R&D, and certification testing.
Standards
ASTM E1530: Standard Test Method for Evaluating Thermal Resistance of Materials Using a Guarded Heat Flow Meter.
ASTM E1560-19: Standard Test Method for Thermal Conductivity Measurements with Guarded Heat Flow Meter.
Parameters
| Item | Specification / Description |
|---|---|
| Applicable Materials | Metals, Polymers, Composites, Pastes |
| Sensor Type | Thermocouples (x6) |
| Measurement Direction | Through-thickness |
| Thermal Conductivity Range | 0.1 – 100 W/m·K * |
| Sample Diameter | 50 – 50.8 mm |
| Sample Thickness | Up to 25 mm (0.1 mm optional for soft materials) |
| Test Time | 40 – 60 minutes |
| Accuracy | 3% (k) |
| Repeatability | 1 – 2% (k) |
| Temperature Range | -20 to 310 °C ** |
| Pressure | Automatic, up to 379 kPa (55 psi) |
| Notes | * Materials with conductivity >60 W/m·K must have thickness ≥12.5 mm ** Each system includes a refrigeration circulator |
Replaceable Heat Flow Module: Tool-free replacement of the calibrated heat flux sensor module.
Comprehensive Temperature Monitoring: Multiple thermocouples ensure sample temperature gradient is at steady-state during testing.
Precision Thickness Measurement: Proprietary universal design allows automated thickness measurement for rigid materials or user-defined thickness/pressure for compressible samples. Optical encoders provide ±0.025 mm accuracy.
Temperature Control: Heat exchanger with thermocouples enables precise heating and cooling; lateral heat loss minimized using guarded furnace; software allows precise temperature programming.
Clamping Control: Automatic clamping for rigid samples; software-controlled height/pressure (up to 379 kPa / 55 psi) for soft materials, with automatic stop once desired parameters are reached.
Steady-State Measurement: Ensures accurate thermal resistance and conductivity by maintaining stable temperature gradients through the sample.
Accessories
Contact paste for top and bottom surfaces.
Optional software module for custom temperature programming.
Standard calibration samples with known thermal resistance and conductivity.
Refrigeration circulator for low-temperature testing.
Send product request
Other supplier products
 |
Goggles Puncture Resistance Testing Machine | Applicable standards: GB 811-2010 ECE R22.05 EN1077 Purpose It is to make a certain weight of sharp objects fall from the height specified i... |
 |
Indicative Fire Resistance Test Furnace ISO 834-1,EN 1363-1Advanced heat insulation test furnace for fireproof coatings | The Fireproof Coating Test Furnace evaluates thermal insulation and fire resistance of steel-structure coatings, complying with GB 14907-2018. It f... |
 |
High-Speed Reciprocating Friction Wear Testing Machine | Whats/App: +86 156 1874 6768 Web: standard-groups.com Applications You can use this tester to: Evaluate the friction and wear performance of va... |
 |
