Aerosol Foams Flammability Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Product Introduction
This product complies with "Recommendations on the Transport of Dangerous Goods - Manual of Tests and Criteria" 31.6 Flammability Test for Aerosol Foams and GB/T 21632 - 2008 Test Method for Flammability of Aerosol Foams in Dangerous Goods.
Standards
GB/T 21632-2008
NY/T 1860
Product Features
1. It adopts an embedded processor and the Windows CE operating system. 2. With an 8 - inch liquid - crystal touch screen, it can display the test status in real - time. 3. It uses highly sensitive photoelectric detection technology to measure the duration of flame combustion and the maximum flame height. 4. Its unique stacked - structure design effectively eliminates backlight interference and is applicable to the judgment of flame heights in various irregular shapes. 5. Automatic judgment of flame height ensures the accuracy of data. 6. It displays test animation images in real - time. 7. It is equipped with a high - precision temperature and humidity module to monitor the temperature and humidity of the test environment in real - time, ensuring the stability of test results. 8. The test process is fully automated, requiring no manual intervention. It supports functions such as parameter setting, data storage, and report viewing.
Technical parameters
| Operating Environment | (5～40)℃, <85%RH |
| Flame Height Detection Range | (0～235)mm |
| Flame Height Detection Resolution | 5mm |
| Combustion Detection Response Time | ≤6ms |
| Ambient Temperature Measurement Range | (-10～+60)℃ |
| Ambient Temperature Measurement Accuracy | ±0.5℃ |
| Ambient Humidity Measurement Range | (5～95)%RH |
| Ambient Humidity Measurement Accuracy | ±5.0%RH |
| Ignition Mode | Gas Igniter |
| Load Glass Size | Ф150mm |
