Flip Phone Durability Tester
Product Introduction:
Mobile clamshell testing machine is a special equipment for mobile clamshell fatigue test.
Its structure design is reasonable, unique, small volume, suitable for limited space location or in the temperature control box test environment. It has full applicability for different models of mobile s. The sensor is used to detect the flip count directly. Stable operation, low noise, maintenance-free.
The instrument is used in laboratories for:
Evaluating the fatigue life and durability of mobile clamshell/hinge mechanisms.
Assessing the long-term mechanical reliability of flip s and foldable smarts.
Simulating repetitive opening and closing actions under controlled conditions.
Identifying potential wear, degradation, or failure points in hinges.
Quality control and assurance during the manufacturing of mobile s.
Research and development of new hinge designs and materials for enhanced durability.
Verifying product performance against internal manufacturer durability standards.
Standards:
GB/T2423.2-2008
IEC60068-2-1
IEC60068-2-2
JEDECJESD22-B111A
ASTMF1977
Product Advantages:
Specifically designed for highly accurate and repeatable mobile clamshell fatigue testing.
Reasonable, unique, and compact structural design, ideal for limited spaces or integration into environmental chambers.
Offers full applicability for testing a wide range of mobile models.
Utilizes a sensor for direct and precise detection of the flip count.
Ensures stable operation with low noise output, minimizing disruption in the lab.
Designed for low maintenance, contributing to continuous testing capabilities.
Features multiple test stations (4 stations) for increased testing throughput and efficiency.
Equipped with a user-friendly touch screen for intuitive operation.
Controlled by a Siemens PLC and driven by a stepper motor for high precision and reliability.
Provides an automatically adjustable swing arm angle (0-180 degrees) for comprehensive testing.
Includes anti-static fixtures to protect test samples.
Technical parameters:
Number of stations :4 / set
Operation mode: touch screen
Control element: Siemens PLC
Action execution component: stepper motor
Swing arm Angle range :0——180 degrees (automatic adjustment)
Clamshell beat :50——30 times/min (automatic adjustment)
Counter :6 bits (built-in)
Fixture: anti-static fixture
