KES-SESRU surface roughness/friction tester
TheRoughness/Friction Tester analyzes hand movements-particularly, strokes-performed by artisans and professionals when judging a fabric' s texture. The device performs this movement mechanically, making it possible to obtain objective numerical data while offering more enhanced versatility over the STD-FB4-A Surface Tester.
In addition to average frictional coefficient and fluctuation of average frictional coefficient, surface roughness data is obtained. The device is also suitable for light texture conditions and hair measurement.
Standards
Compatible with standards of ISO1997, ANSI and JIS2001
Features
Sensor that imitates fingertips
The sensor unit’s design features a load and surface treatment that mimics a fingertip, allowing for quantification similar to that of the human fingertip.
Parameter
| Product Name | Roughness/Friction Tester |
| Dimensions (W×D×H) *approx. | Measuring unit: 320×200×390 mm Amplifier: 180×400×400 mm |
| Weight *approx. | Measuring unit: 10 kg Amplifier: 12 kg |
| Power supply, Frequency | 100VAC, 50/60Hz |
| Interface | STD-USB (optional) PC (optional)*1 Data logger output terminal |
| OS | Windows 7/8/8.1/10 |
| Sample size | 30×270 mm (standard) |
