Wire Cut - through Tester for Ford Automotive Wires
Applicable Standard:
Engineering Specification - Ford Global Wire specification, PART NO. ES - AU5T - 1A348 - AA
Technical Parameters:
1. Sensing method: High - precision load cell (sensor)
2. Capacity: 200KG
3. Cut - through speed: 10mm/min
4. Effective measurement range (%): 0.5 - 100
5. Accuracy class: Grade 1
6. Load accuracy: Within ±1% of the indicated value
7. Display: Controlled and recorded by computer software
8. Equipped with an automatic stop function upon cut - through
9. Overload protection: The machine will automatically activate protection when the load exceeds the maximum by 10%
10. Power system: AC servo motor
11. Fixture configuration: One set of fixtures selected according to the user's product requirements
12. Power supply: AC 220V±10%, 50HZ, 5A
13. Dimensions: 56X80X170cm
14. Diameter of the cut - through steel wire: 0.45mm
15. Cut - through test voltage: Less than 24V
Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
