Bag Plastic Buckle Durability Tester
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
It is mainly used to test the service life of plastic plug-ins in luggage accessories.
Applications
This machine simulates the use of plastic clasp under reciprocating open and close movement to a specified number of times at a certain frequency. And testing the quality of plastic clasps for luggage and clothing.
Standards
QBT 5247-2018:Hardware fitting of case and bag-Test method for durability of plastic buckle
Features
1. We have a strong after-sales service team;
2. We can handle various problems promptly and efficiently, relieving our customers of any worries;
3. We have a complete range of spare parts, eliminating the hassle of long lead times for ordering parts;
4. We keep up with industry standard updates and provide testing instruments that meet the latest standards in a timely manner.
Technical Parameters
| Parameter | Specification |
|---|---|
| Control System | PLC+ Touch Screen (Man-machine interface control system with easy operation and power-off saving function) |
| Counting | 0——999 999 times, automatic stop function when reaches set amount and setting the insertion and extraction times functions in the man-machine interface |
| Drive Motor | High precision servo motor control, stable speed, lower noise, long life span. The right fixture seat can be controlled to left and right movement and positioning speed and angle is accurate than ordinary cylinder |
| Frequency of the Right Clamp | 25±1/ min |
| Open and Close Cylinders | 2 yadeke cylinders |
| Cushion Hydraulic Cylinder | 2 |
| The Right & Left Clamps | Convenient to adjust the samples under different position. This structure adopts a combination of mechanical and pneumatic design |
| Air Supply | exceeding 6kg/cm² |
| Servo Motor | 400w |
| Power Supply | Single phase, AC220V, 50/60HZ |
