Thermal cycle wet freezing testing machine
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
The Thermal Cycle Wet Freezing Testing Machine is designed for comprehensive environmental testing, capable of simulating extreme temperature and humidity conditions. It provides precise control and high repeatability for accelerated aging, condensation resistance, and reliability testing of batteries, photovoltaic modules, and electronic components. Its dual-chamber design ensures simultaneous wet and dry testing, enabling efficient evaluation under multi-environment conditions.
Application
(1) Environmental performance testing of lithium-ion batteries and battery modules
(2) Design qualification and type approval testing for photovoltaic (PV) modules
(3) Reliability and durability testing of electronic control units (ECUs) and PCBA
(4) Research and development for automotive and renewable energy components
Standards
(1) IEC 61215 – Terrestrial Photovoltaic (PV) Modules: Design Qualification and Type Approval
(2) UL 1073 – Safety of Enclosures for Electrical Equipment
(3) ISO 16750-4 – Road Vehicles: Environmental Conditions and Testing for Electrical and Electronic Equipment
(4) CE Certification – Conformité Européenne
(5) RoHS Compliance – Restriction of Hazardous Substances
(6) Optional: IEC 60068 series for environmental testing of electronic equipment
Features
Extreme Environmental Simulation: -40°C to +85°C operational range; 98% RH humidity control.
Ultra-Stable Performance: ±1°C temperature stability and ≤±2°C uniformity across chamber.
Rapid Transient Response: 10°C/min heating and 7°C/min cooling with auto-tuning PID.
Energy Efficiency: Advanced insulation and heat recovery for 40% lower power consumption; ECO mode for idle periods.
Safety Features: Dual overload protection, thermal cutout, current-limiting breaker, and door interlock.
User-Friendly Interface: 10” touchscreen HMI with preloaded test profiles and customizable hold times.
Remote Monitoring: Wi-Fi/Ethernet connectivity with real-time alerts via SMS or .
Glovebox Compatibility: Controlled oxygen and moisture levels for sensitive component testing.
Parameters
| Parameter | Specification |
|---|---|
| Temperature Range | -40°C to +85°C (operational) |
| Temperature Fluctuation | ≤ ±1°C |
| Temperature Deviation | ≤ ±1°C (steady state) |
| Temperature Uniformity | ≤ ±2°C (empty chamber) |
| Heating Rate | 10°C/min (typical, configurable) |
| Cooling Rate | 7°C/min (typical, configurable) |
| Humidity Range | 30%–98% RH (non-condensing) |
| Humidity Deviation | ±3% FS (at 85% RH ±2%, 90% RH ±2%) |
| Chamber Volume | 500 L (standard), expandable to 1,500 L |
| Power Supply | 380V/415V, 3-phase, 50/60Hz |
| Dimensions (W×D×H) | 1,200 mm × 1,800 mm × 2,000 mm |
| Weight | 800 kg (net) / 1,200 kg (gross) |
