ISO 12103 Cleanable Filter Media Test System
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standards
The system complies with:
(1) VDI 3926-2 – Test guideline for cleanable filter media.
(2) ASTM D6830-02 – Laboratory scale air filter test method.
(3) ISO 12103-1 – Standard test dust for filter efficiency evaluation.
(4) ISO 5011 – Air filter testing for engines and machinery.
Parameters
| Parameter | Unit | Value |
|---|---|---|
| Test Flow Rate | m³/h | 2 … 64 |
| Differential Pressure Measuring Range | Pa | – |
| Duration of Pressure Pulse | ms | 50 … 150 |
| Pressure Tank Capacity | bar | 2 … 6 |
| Test Specimen Dimensions | mm | Diameter ≤ 150 |
| Power Supply | – | 3 × 400 VAC, 16 A |
| Operating Medium (Aerosol) | – | Pural-NF, Pural-SB, DEHS |
| Sensors | – | Temperature, relative humidity |
| System Dimensions (W × H × D) | mm | 2800 × 1500 × 800 |
| Weight | kg | approx. 120 |
Features
Standardised Filter Testing: Supports alumina oxide aerosols (Pural NF, Pural SB).
Automated Operation: Up to 14 hours of unattended testing.
Multi-Aerosol Capability: Solid and droplet aerosols supported.
Flexible Design: Rapid modification for future tests and additional features.
Operator-Friendly Control: Intuitive software interface for setup, monitoring, and data logging.
Compact Laboratory Use: Lightweight and portable, suitable for small-scale testing.
Accessories
| Accessory | Description |
|---|---|
| Atomizer Aerosol Generator | Generates fine aerosol for filtration testing |
| Solid Materials Disperser | Produces solid aerosol particles for standardised tests |
| Aerosol Dilution System | Dilutes aerosols to desired concentration |
| Aerosol Spectrometer | Measures particle size distribution and filtration efficiency |
Test Principle
The system draws controlled airflow through filter media while applying standardized aerosol particles (solid or droplet). Differential pressure, fractional efficiency, and dust loading are continuously measured. Data acquisition provides detailed insight into the filtration performance and operational characteristics of the media under laboratory conditions.
Operation Instructions
Safety:
Ensure electrical connections are properly installed.
Maintain laboratory ventilation when using aerosols.
Operators should wear gloves and safety goggles during aerosol handling.
Setup:
Mount the filter media securely on the test platform.
Select aerosol type and configure airflow and pressure pulse parameters.
Verify sensors and calibration before starting the test.
Testing:
Start automated test sequence.
System injects aerosol, measures differential pressure, and records filtration efficiency and dust loading.
Data is logged automatically for analysis.
Post-Test:
Review differential pressure curves, fractional efficiency, and dust loading capacity.
Export reports for quality control and research documentation.
Maintenance Information
Regularly clean aerosol generators and dispersers.
Calibrate pressure sensors periodically.
Inspect control software and data acquisition systems for updates.
Maintain system cleanliness to prevent contamination.
