International rubber hardness tester
Technical parameters:
1, hardness effective measurement range: 30-95IRHD
2, initial load （contact force） : 8.3±0.5mN
3, the main load （pressure such as force） : 145±0.5mN
4, total force: 153.3±1.0mN
5, pressure on the foot force: 235±30mN
6, pressure ball diameter: 0.395±0.005mm
7, pressure foot diameter: 3.35±0.15mm
8, the thickness of the standard test piece is 2mm±0.5mm （the thickness of the rubber test piece can be measured from 1 to 6.5mm）
9, can be measured rubber O-ring diameter range: Φ1——Φ6.5mm
10, AC power supply: 220V±10%, 50HZ
11,Overall size: 250×280×290mm
12,Weight: 10 kg
Meet the standard:
GB/T6031-2017, ISO48 international standard, ASTM D1415 standard, etc
