Dental Implants Fatigue Tester
Производитель: Шанхайская компания Qianshi Precision Electromechanical Technology Co., Ltd
Все товары поставщика
Все товары поставщика
Standard
- ISO 14801:2016: Specifies dynamic fatigue testing protocols for endosseous dental implants, including load ratios, frequency, and failure criteria.
- YY/T 0521-2018 (China): Defines methodologies for evaluating the fatigue strength of dental implant-abutment complexes under cyclic loading.
Product Advantages
- Electromagnetic Precision: Novel servo motor technology ensures backlash-free operation with 0.001 mm displacement resolution.
- Biorelevant Simulation: Integrated 37°C water bath system replicates physiological conditions for in vitro corrosion testing.
- Universal Fixturing: Adjustable angle clamps accommodate straight/angulated implants (0°–25° pre-set options).
- High-Frequency Stability: 20 Hz operation with ±0.05% load accuracy across 2 million cycle tests.
- Compact Design: Benchtop footprint (450 × 400 × 600 mm) suits laboratory environments.
- Regulatory Compliance: Pre-loaded ISO 14801 protocols with automated data reporting for FDA/CE submissions.
Product Features
- Electromagnetic Servo Actuator: 600 N dynamic load capacity with programmable R=0.1–10 ratios.
- Dual Sensor System: 0.01 N resolution load cell + 0.001 mm LVDT displacement transducer.
- Dynamic Load Control: 0.1–20 Hz frequency range with sine/square/random waveforms.
- Thermal-Mechanical Bath: 37±0.5°C recirculating water system with anti-evaporation design.
- High-Resolution Imaging: Built-in 2MP camera system for fretting corrosion analysis.
- Safety Suite: Emergency stop, overload clutches, and water leak detection system.
Technical Parameters
| Parameter | Specification |
|---|---|
| Max. Dynamic Load | ±600 N (0.01 N resolution) |
| Frequency Range | 0.1–20 Hz (0.01 Hz increments) |
| Load Ratio (R) | 0.1–10 (adjustable) |
| Displacement Range | ±5 mm (0.001 mm resolution) |
| Water Bath Temperature | 37±0.5°C (PT1000 sensor) |
| Data Sampling Rate | 10 kHz (synchronized across 8 channels) |
| Power Requirements | 220V/110V ±10%, 50/60Hz, 1,200W |
| Dimensions (W×D×H) | 450 × 400 × 600 mm |
| Weight | 55 kg (net) / 65 kg (with water bath) |
| Noise Level | <55 dB (A-weighted) |
Accessories
- Dental Implant Fixture Kit:
- Adjustable angle clamps (0°–25° pre-set options)
- Self-centering abutment adapters (3.0–6.5 mm compatibility)
- Thermal-Mechanical Bath:
- 10L capacity with recirculating pump
- Corrosion-resistant titanium interior
- FatigueMaster Pro Software:
- Automated S-N curve generation and fatigue limit calculation
- 21 CFR Part 11-compliant audit trail with blockchain timestamping
- Remote monitoring via iOS/Android app
- Operator Kit:
- Calibrated torque wrench set (0.1–10 Nm)
- Implant alignment jigs (ISO 14801 compliant)
- Calibration Bundle:
- NIST-traceable force calibration weights
- LVDT verification tool
- Safety Kit:
- Water leak detection system
- Acoustic enclosure with 25 dB noise reduction
