Photovoltaic module wire tube bending testing machine
Standard
- IEC 61730-2:2004: Photovoltaic (PV) Module Safety Qualification – Requirements for Testing
- CE Certification(Conformité Européenne)
Product Advantages
- IEC 61730-2 Compliance
- 120 Hz Max Frequency: Simulates 20+ years of cable flexing in 1,000 hours.
- 1–9,999s Timing: Customizable test durations for accelerated life testing.
- Precision Control
- 0.1 Hz Resolution: Ensures repeatable bending cycles per IEC standards.
- Auto-Stop at Failure: Immediate cycle interruption during conduit cracking.
- Energy Efficiency
- 100W Power Consumption: Low-energy servo motor design.
- Sleep Mode: Auto-powers down between test sequences.
- Safety First
- Emergency Shutoff: Dual redundant safety circuits with E-stop button.
- Overload Protection: 150% max torque cutoff for delicate wires.
- User-Centric Design
- 7” HD Touchscreen: Multi-touch gestures for live force-displacement graphing.
- Voice-Guided Setup: Step-by-step audio prompts for operators.
Product Features
- Quick-Change Fixtures: Adapts to 2–20 mm diameter PV cables/conduits.
- Dynamic Force Feedback: 0.1N resolution load cell with real-time bending angle display.
- Self-Calibrating System: Auto-tare and linearity checks before each test.
- Rust-Resistant Frame: 304 stainless steel construction with epoxy coating.
- Data Logging: USB/Ethernet export of test cycles, peak forces, and failure points.
Technical Parameters
| Parameter | Specification |
|---|---|
| Frequency Range | 0–120 Hz (adjustable) |
| Spindle Speed | N RPM = Frequency Hz / 60 |
| Timing Range | 1–9,999 seconds (1–166.65 minutes) |
| Force Resolution | 0.1N (10 kgf max capacity) |
| Bending Angle Accuracy | ±1° (via rotary encoder) |
| Power Supply | 220V AC, 50/60Hz (single-phase) |
| Dimensions | 500mm (W) × 400mm (D) × 600mm (H) |
| Weight | 45 kg (net) / 60 kg (gross) |
Accessories Included
- Testing Kit:
- 10x conduit clamps (2–20 mm range).
- 5x calibration weights (1N–10N).
- Software Suite:
- License key forBendTest Pro(Windows/macOS).
- 1-year free access to cloud-based fatigue analysis tools.
- Calibration & Safety:
- NIST-traceable torque wrench.
- Insulated gloves (Class 0, 3 pairs).
- Maintenance Kit:
- Spare drive belts and bearings.
- Machine cleaning solution (non-corrosive).
- Documentation:
- Multilingual quick-start guide (printed + digital).
- Compliance certificates for IEC/UL/ISO standards.
