Photovoltaic module wire tube bending testing machine

Photovoltaic module wire tube bending testing machine
  • Photovoltaic module wire tube bending testing machine
供应商: 上海千实精密仪器

供应产品
在线联系供应商

Standard

  • IEC 61730-2:2004: Photovoltaic (PV) Module Safety Qualification – Requirements for Testing
  • CE Certification(Conformité Européenne)

Product Advantages

  1. IEC 61730-2 Compliance
    • 120 Hz Max Frequency: Simulates 20+ years of cable flexing in 1,000 hours.
    • 1–9,999s Timing: Customizable test durations for accelerated life testing.
  2. Precision Control
    • 0.1 Hz Resolution: Ensures repeatable bending cycles per IEC standards.
    • Auto-Stop at Failure: Immediate cycle interruption during conduit cracking.
  3. Energy Efficiency
    • 100W Power Consumption: Low-energy servo motor design.
    • Sleep Mode: Auto-powers down between test sequences.
  4. Safety First
    • Emergency Shutoff: Dual redundant safety circuits with E-stop button.
    • Overload Protection: 150% max torque cutoff for delicate wires.
  5. User-Centric Design
    • 7” HD Touchscreen: Multi-touch gestures for live force-displacement graphing.
    • Voice-Guided Setup: Step-by-step audio prompts for operators.

Product Features

  • Quick-Change Fixtures: Adapts to 2–20 mm diameter PV cables/conduits.
  • Dynamic Force Feedback: 0.1N resolution load cell with real-time bending angle display.
  • Self-Calibrating System: Auto-tare and linearity checks before each test.
  • Rust-Resistant Frame: 304 stainless steel construction with epoxy coating.
  • Data Logging: USB/Ethernet export of test cycles, peak forces, and failure points.

Technical Parameters

ParameterSpecification
Frequency Range 0–120 Hz (adjustable)
Spindle Speed N RPM = Frequency Hz / 60
Timing Range 1–9,999 seconds (1–166.65 minutes)
Force Resolution 0.1N (10 kgf max capacity)
Bending Angle Accuracy ±1° (via rotary encoder)
Power Supply 220V AC, 50/60Hz (single-phase)
Dimensions 500mm (W) × 400mm (D) × 600mm (H)
Weight 45 kg (net) / 60 kg (gross)

Accessories Included

  1. Testing Kit:
    • 10x conduit clamps (2–20 mm range).
    • 5x calibration weights (1N–10N).
  2. Software Suite:
    • License key forBendTest Pro(Windows/macOS).
    • 1-year free access to cloud-based fatigue analysis tools.
  3. Calibration & Safety:
    • NIST-traceable torque wrench.
    • Insulated gloves (Class 0, 3 pairs).
  4. Maintenance Kit:
    • Spare drive belts and bearings.
    • Machine cleaning solution (non-corrosive).
  5. Documentation:
    • Multilingual quick-start guide (printed + digital).
    • Compliance certificates for IEC/UL/ISO standards.
