Voltage Drop Tester for Automotive Wire Connectors
Technical Features:
This instrument features adjustable high - current output, micro - voltage testing, and digital tube display.
Main Parameters:
1. Input voltage: AC220V + 10%, 50Hz
2. Working current (DC): 0 - 100A (optional values including 5A, 10A, 20A, 50A, 100A, 200A, 500A, 1000A) and can be adjusted arbitrarily
3. Current output mode: Constant current
4. Voltage drop range: 0 - 20V (with three voltmeters of different accuracies for 0 - 200mV / 0 - 2V / 0 - 20V). The display ranges are 0.01 - 199.99mV / 0.1 - 1999.9mV / 1 - 19999mV respectively
5. Power: 3200W, maximum output voltage: 32V
Send product request
