Sweating Guarded Hot Plate Tester STD-AG48
Test Principle
Under standard test environment, heat the fixed aluminum or copper plate and keep a fixed temperature, test the heating power, then test the power of the same situation after covering the sample cloth, to get the hermal and evaporative of clothing material.
Feather
With a heat plate fully simulated human skin mechanism, Easy to clean.
Automatic water supply system, can ensure the stability of the water supply and does not leak do not require any adjustment.
Instrument can automatic adjustment of PID control parameters based on sample thickness to achieve the test conditions.
Wind speed continuously adjustable from 0-1.2m/s, to meet variety test standard for thermal resistance, wet resistance and heating performance test.
The width of the thermal protection ring is 127mm to ensure that the heat flow is transmitted only from the test sample
Can connect WIFI with computer.
Standards
GB/T11048. ISO11092. ASTMF1868-09. BS 8515. ASTM D 1518-2014. JIS L1096-2010. ASTM F 1868-02
Key Specification
|
Model |
STD-AG48 Sweating Guarded Hot Plate Tester |
|
Thermal resistance (RCT) range |
0.002~2.0 m2.K/W |
|
Wet resistance (RET) range |
0~1000 m2.Pa/W |
|
Test board temperature range |
30℃~40℃, adjust |
|
Temperatureprecision |
±0.03℃ |
|
Wind speed |
0-1.2m/s, continuous adjustable |
|
Wind speed precision |
±1% |
|
Test sample thickness |
0-50mm |
|
Test plate area |
254mm×254mm |
|
Sample area |
512mm×512mm |
|
Thermal ring width |
127mm |
|
Power supply |
AC220V, 50/60HZ |
|
Dimension |
73×61×35cm |
|
Weight |
60Kg |
