Sole heat resistance testing machine丨Sole heat resistance tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Main uses:
The sole heat resistance tester is used to test the heat resistance and temperature insulation performance of finished shoes under high temperature sand and stone heat temperature medium.
Reference standard:
EN ISO 20344. EN ISO 8772-1. GB/T 20991-2007. ANSI, JIS, CSA, GB12017-1989. LD50-1994 and other standards
Test principle:
The sandbox is heated to 150℃， the sand covers the contact point between the sample upper and the sole, and the change of the insole temperature over 30 minutes is recorded, accurate to 0.5℃。
Technical parameters:
Sand bath box size: (40±2)cm*(40±2)cm, height: 8cm
Sand height: ≥5cm
Sand size: (0.3 —— 1.0)mm
Sand volume: 5000±250cm
Test temperature: (150±5)℃ or (250±5)℃
Heating power: 2500±250W or more
Heat transfer medium: 5mm steel ball, total mass 4kg
Copper/copper-nickel thermocouple: Solder a copper disc 2±0.1mm thick and 15±1mm diameter
Send product request
