PTFE Coated Glass Fabric Adhesive Tape
PTFE coated glass fabric adhesive tapeuses a material made of glass fiber cloth impregnated with a tetrafluoroethylene resin (PTFE) dispersion solution and fired as the base material. PTFE coated glass tapehas one surface treated with silicone adhesive and has excellent heat resistance and mechanical strength. Economical high-temperature cloth is mostly used in sealing machine, packaging machine, high frequency, high-temperature air duct, etc. The common thickness of ptfe coated glass cloth tapeis 0.08 mm, 0.13 mm, 0.15 mm and 0.18 mm and 0.25 mm, other requirements can be customized.
The common thickness of our high-performance high-temperature cloth is 0.08 mm, 0.13 mm, 0.15 mm, 0.18 mm, 0.25 mm, 0.30 mm, 0.35 mm, and 0.55 mm, 0.75 and 0.95 mm. The high heat Teflon tape produced by Hopelight can be used in breathable remoulding, anti-static, military, printing and dyeing, clothing, electronics, chemicals, glass, medicine, thermoplastics, wrapping rollers, paper making, food, environmental protection, insulation, machinery, and many other fields.
Laminated cloth (small laminators can be within 1.25 meters wide, large laminators have widths of 1.8, 2.0, 2.2, 2.4 meters, and the length varies, generally within 6 meters.) Common thicknesses are: 0.25, 0.30, 0.35 mm etc.
PTFE Coated Glass Fabric Adhesive Tape-TDS
|
Thickness(mm) |
width(mm) |
Adhesion(N/100mm) |
Tensile strength(N/100mm) |
Temp resistance(℃) |
Color |
|
5mm-1250 |
22 |
900 |
-70~260 |
Amber/black/white |
|
|
5mm-1250 |
28 |
1700 |
-70~260 |
Amber/black/white |
|
|
5mm-1250 |
48 |
2750 |
-70~260 |
Amber/black/white |
|
|
5mm-1250 |
62 |
3650 |
-70~260 |
Amber/black/white |
Application Of ptfe glass fibre tape
Heat-sealed and pressure-bonded parts for packaging food, rice bags, medicines, etc.
Teflon tape is used for heat sealing of plastic film
Surface of precision pressing stick for packaging dyeing and counting fat processing
Packaging adhesives, the surface of the sticker coating machine
The friction surface of packaging hopper and guide rail.
Packaging non-adhesive and parts that need to maintain smoothness
As the inner lining of equipment accessories
PTFE fabric tapeis used as an insulating liner, insulating overlook of insulating parts and other insulating overlooks
Features Of teflon coated glass fabric
Safe and non-toxic, suitable for food production;
Withstand the corrosion of almost all chemicals;
Good dimensional stability and strong tensile strength, with good mechanical properties;
High insulation performance (small dielectric constant: 2.6, tangent below 0.0025);
Resistance to microwave, high frequency, anti-purple and infrared.
Flame retardants: the oxygen limit index is below 90, and the combustion level: V-0
As one of the most professional glass cloth tape suppliers, we provide heat resistant teflon tape,aluminium tape, china high temperature tapeand etc. Want to know more? Please contact us.
