Multimeter MF500 high-precision mechanical pointer meter inner magnetic outer magnetic 2500V.
The MF500 series multimeter is a portable rectifier system with high sensitivity and multiple limits. It can measure AC and DC current, AC and DC voltage, DC resistance and audio level separately. It is suitable for radio, telecommunications and electrician institutions as general measurement.
Features:
- The MF500 multimeter shell is made of phenolic compression molding powder, which has good mechanical strength and electrical insulation performance.
- The instrument is equipped with a sealing device to reduce the external dust and harmful gas from eroding the inside of the instrument.
- The dial of the instrument is wide, and the end of the pointer is knife-shaped, so it can clearly indicate the measured value.
- The battery box is located on the back of the meter and isolated from the inside of the meter, so it is convenient to replace the battery.
- The volume of the instrument: 178X 173X84 mm;
SPECIFICATIONS:
- DC Voltage: 2.5 / 10/50/250/500 V / 2500 V
- AC Voltage: 10/50/250/2500 V
- Current DC: 0.5mA / 1mA / 10mA / 100mA / 500mA
- Resistance: R2K / R20K / R200K / 2MΩ / 20MΩ
- Dimensions: 178 * 138 * 84mm
- Weight: about1450g
- Power supply: 1.5V C battery × 1 + 9V 6F22 battery * 1 & # 65288; without battery & # 65289;
- Accessories: test leads, Manual
- weight: ≈ more than 1 kg.
CHARACTERISTICS:
- MF500 multimeter is a high sensitivity, portable, rectifier-based instrument.
- The instrument has twenty-four ranges, respectively, can measure AC and DC voltage, DC current, resistance, and audio level.
- basic function: DCV ACV DCA Ω etc.
- mirror feature scale for accurate reading
- Classic design
- magnetic internal board head
- Bakelite shell
- overload protection.
