Wine Cellar Cooling Units Split System / HSN-J60
Thenow wine cellar refrigeration split systemis intended for cellars without access to proper ventilation. They are known for their efficiency and longevity. Each unit is designed to maintain a consistent temperature and humidity in spaces where proper ventilation is not feasible. The evaporator is installed inside and the condensing unit can be placed as far as 30m away. Since it exhausts outside, split cooling systems operate quietly and reduce vibration inside the cellar, which is believed to negatively affect the quality of wine.
ThenowWine Cellar Cooling Units Split System / HSN-J60 Features:
Auto cooling and heating mode, keep wine cellar under constant temperature.
The evaporator is nickel plated for corrosion protection
Adopt circulating water wet-film auto control humidification system,wet film is made of Swedish organic polymer material with sterilization and disinfection function.
Full touch control system, famous brand sensors, stable quality and performance.
Pull-out design wet film module, easy to replace
Control constant condensation temperature
Three speed air flow under auto control to maintain the ideal environment for long-term wine storage
Can be ceiling mounted, rack mounted, or floor mounted
The specific parameters of Wine Cellar Cooling Units Split System / HSN-J60
|
Model |
Unit |
HSN-J60 |
|
Cellar Size (Up to) |
m³ |
60 |
|
Power |
P |
2 |
|
Power Supply |
V/HZ |
220V/50Hz |
|
Cooling |
W |
3100 |
|
Heating (Electrical) |
W |
6000 |
|
Air Flow |
m3/h |
740 |
|
Static Pressure |
Pa |
30 |
|
Noise |
dB（A） |
50 (Indoor) |
|
Refrigerant |
/ |
R410A |
|
Controller |
PC Full-touch smart control |
|
|
Temperature |
℃ |
10-16℃, ±2℃ |
|
Humidity |
℃ |
50~70%, ±5% |
|
Total Power |
W |
7400 |
|
Humidifier |
Type |
Wet-film |
|
Humidification |
Kg/h |
2 |
|
Indoor Unit Size |
L*W*H(mm) |
1345*790*300 |
|
Outdoor Unit Size |
L*W*H(mm) |
860*300*540 |
|
Tube Connection |
Liquid(mm) |
|
|
Gas(mm) |
