10'' Android: EM-Q15 Multi-module Tablet PC
10 inch Qualcomm cost-effective rugged tablet.
10000mAh battery supports hot-swap, improve the endurance to make sure the working time 6-8 hours.
Support ID card, fingerprint, UHF and other special module combinations. Meet the needs of multiple industries.
Features of 10'' Intel: EM-Q15 Rugged PC
Support for Android 9.0 system
Integrated 3G/4G all network communication, WiFi, Bluetooth and other communication modes
10000mAh battery, 7 hours of machine endurance
IP65 high protection level, in accordance with MIL-STD-810G
Support GPS, Glonass, more accurate positioning
800x1280 IPS, 700nit high brightness screen, more suitable for outdoor harsh environment
Support 1D / 2D, UHF, NFC, ID card and other functional modules for free selection
Specifications of 10'' Android Tablet EM-Q15 Rugged PC
|
Type |
Details |
Standard Configuration |
Optional |
|
Product Form |
Type |
Rugged Tablet |
NA |
|
Dimension |
280*180*25.8 mm |
NA |
|
|
Weight |
Device unit: 1068g ，Unit with giftbox and standard accessories:g， |
NA |
|
|
Device Color |
black( bottom shell in black, front shell in black) |
NA |
|
|
LCD |
Screen Size |
NA |
|
|
Resolution |
800*1280 IPS LCD |
NA |
|
|
Brightness |
Minimum 700cd/㎡ |
NA |
|
|
TP |
Touch Panel |
10points Capacitive，G+G，Rigidity: above 7H-Anti-scratch,TP thickness：1.1mm，COF,support pen |
NA |
|
Camera |
Front |
Front:5.0MP |
NA |
|
Rear |
Rear: 13MP auto-facus with flashlight |
NA |
|
|
Speaker |
build in |
Embedded 8Ω/0.8W waterproof speakerx 1 |
NA |
|
Mic |
build in |
Sensitivity:-42db, output resistance2.2kΩ |
NA |
|
Battery |
Type |
build in polymer li-ion battery |
NA |
|
Capacity |
NA |
||
|
Endurance |
nearly 7 hours ( 50% volume sounds,50% brightness, 1080P HD video display by default ) |
NA |
|
|
System Hardware Configuration |
|||
|
Type |
Details |
Description |
Optional |
|
CPU |
Type |
MSM 8953 |
NA |
|
Speed |
NA |
||
|
GPU |
type |
Adreno 506 1920 × 1200 @ 60 fps |
NA |
|
RAM |
Memory |
4GB/ LPDDR3 |
NA |
|
ROM |
storage |
64GB |
NA |
|
Indicator light |
build in |
Indicator light of charge, red light will flash when device has low power. red long light when charging, green long light when full power |
NA |
|
Compass |
Built-in |
Compass Sensor *1 |
NA |
|
Gyro Sensor |
Built-in |
Gyro Sensor *1 |
NA |
|
G_sensor |
build in |
Gravity acceleration sensor |
NA |
|
Network Connections |
|||
|
Type |
Details |
Description |
Optional |
|
WIFI |
WIFI module |
WIFI 802.11 b/g/n/a/ac frequency 2.4G+5G dual band WIFI, |
NA |
|
Bluetooth |
build in |
NA |
|
|
2G/3G/4GB |
build in |
LTE FDD: B1/B3/B5/B7/B8/B20/B28ALTE TDD: B38/B40/B41WCDMA: B1/B2/B5/B8GSM: 850/900/1800/1900MHz |
NA |
|
GPS |
build in |
support:GPS+Glonass;Capture sensitivity:-140 dBm；Cool Start Time：<50秒，Hot start time：<5秒，GPS frequency：1575.42MHz，Glonass frequency:1602MHZ |
NA |
|
serial port |
optional |
NA |
RS232 |
|
Ethernet interface |
optional |
NA |
*1(10/100M self-adaption) with indicator light |
|
NFC |
build in |
NFC－ST21 |
NA |
|
ID Module |
optional |
NA |
support reading the fingerprint information in the 1st and 2nd ID card Port：USB or TTL serial port optionalpower 5v or 3.3v，size：53mm*52mm*10mm |
|
UHF |
optional |
NA |
UFH，Working spectrum range902Mhz – 928Mhz,inventory tag peak velocity > 50 pcs /second， |
|
the fingerprint module authenticated by Chinese Ministry of public security |
optional |
NA |
Fingerprint collection module for Resident identity card:standard UART/ USB port,Baud rate 115200bps(by default),Sensor type：Semiconductor capacitance，Image size 256 * 360 pixel,working voltage 3.8~5V,Working current 50mA,Standby current 35mA,size：35mm*23mm*3.4mm |
|
Data Collection |
|||
|
Type |
Details |
Description |
Optional |
|
1D |
OPTIONAL |
NA |
Honeywell N4313 |
|
optical resolution:5mil |
|||
|
scan speed:50次/s |
|||
|
support code system:UPC/EAN, Bookland EAN ,UCC Coupon Code,ISSN EAN,Code 128,GS1-128,ISBT 128,Code 39,Trioptic Code 39 ,Code 32,Code 93 ,Code 11 |
|||
|
2D |
OPTIONAL |
EM80 |
EM80 |
|
optical resolution:5mil |
|||
|
scan speed:50次/s |
|||
|
support code system:PDF417, MicroPDF417, Data Matrix, Data Matrix InverseMaxicode,QR Code, MicroQR, QR Inverse,Aztec,Aztec Inverses,Han Xin,Han Xin Inverse |
|||
|
Interface Configuration |
|||
|
Type |
Details |
Descriptions |
Optional |
|
SIM Card |
SIM Card |
SIM card x2 in tablet |
NA |
|
TF Card |
TF Card |
x1 max：128G |
NA |
|
USB Interface |
Extend external memory and data transfer |
Standard USB 2.0*1 TypeC x1（data&charing） |
NA |
|
Ear Jack |
Audio Output |
∮3.5mm standard ear jack x1 |
NA |
|
DC Jack |
Power |
DC 5V 3A ∮3.5mm Power connector x1 |
NA |
|
HDMI |
Video Output |
Mini HDMI x1 |
NA |
|
Extensive Slot |
pogo Pin |
12pin Pogo Pin x1 |
NA |
|
Keys |
Keys |
Power*1、Vol*2，P*3 |
NA |
|
Standard Accessories |
|||
|
Type |
Details |
Description |
Optional |
|
OTG cable |
OTG cable |
USB OTG to MICRO USB cable length:45mm |
NA |
|
USB cable |
USB cable |
USB to micro 5P L=1.2M 4core aluminum foil shield cable |
NA |
|
Power Adaptor |
Standard |
AC100V ~ 240V、50Hz/60Hz output DC 5V/3A USA Standard CE approval |
UK standard |
|
EU Standard |
|||
|
Software Configuration |
|||
|
Type |
Details |
Description |
Optional |
|
Operation System |
OS version |
Android 9.0 |
|
|
Product Certificate |
|||
|
Type |
Details |
Description |
Optional |
|
Certificate System |
IP65 |
IPX5Method name：short time submerging testtest device and test condition：submerge water box。the size should make the testing sample into submerge box and after then , the distance from sample bottom to water surface at least 1m. and distance from sample top side to water surface at least 0.15m.Testing time: 30 min |
IP67 optional |
|
CE NB |
Y |
||
|
MIL-STD-810G |
Y |
||
|
Battery |
|||
|
Reliability |
|||
|
Type |
Details |
Descriptions |
Optional |
|
Product Reliability |
Drop Height |
MIL-STD-810G 1.22m drop |
|
|
Operate Temperature |
‘-20 °C to 55 °C |
||
|
Store Temperature |
’-30 °C to 70 °C |
||
|
Humidity |
Humidity: 95% Non-Condensing |
||
Accessories of 10'' Android Tablet EM-Q15 Rugged PC
Various modules and accessories can be selected to meet customers' application in various industries.
Shenzhen Emdoor Information Co., Ltd. is a rugged computer manufacturer,we provide rugged computer, rugged medical tablet, ruggedized industrial pc, rugged android tablet 10 inch, etc. Contact us to buy rugged computer. We will provide our customers with sincere service and excellent products.
