Frame & chassis powder coatings MT-A400 series
Product Overview:
Weather-resistant pure polyester powder coatings designed for frame and chassis parts
Coating characteristics:
– High corrosion resistance
– Excellent bending resistance
– Excellent stone impact resistance and UV resistance
Application:Suitable for frame and chassis parts of various models
Application parameters:
Curing time: 180~200tCx10~15 minutes
Spraying method: high voltage electrostatic spraying 60~80KV
Physical properties
Recommended film thickness: 60-150 um
| Project | Instrument | Judgment standard | Test standard |
| Pencil hardness | Pencil hardness tester | A 1H | GB/T 6739 ASTM D 3363 |
| Impact resistance | Impact tester | 50 kg.cm (8mm diameter)
2.5Nm (16mm diameter) (20mm diameter) |
GB/T1732 ASTM D 2794 ISO 6272 |
| Bending resistance | Bending tester | v2mm
Cylindrical shaft |
GB/T 6742
ASTM D 1737 |
| Adhesion | Hundred grid test | Grade 0 | GB/T 9286 ISO 2409 ASTM D 3359 |
| Cupping | Cupping instrument | M 6 mm | GB/T9753 ISO 1520 |
| Salt spray resistance | NSS salt spray | &600H, WbW2mm | GB/T1771 ASTMB-117 ISO 7253 |
| Moisture and heat resistance | Constant temperature and humidity chamber | M 1000H slight gloss loss | GB/T1740 ISO 6270 |
| Weather resistance | Aging test chamber | QUV-B313 500H N 3 level | GBZT 1865 ISO 11341 |
| Motor oil resistance | L—E10# | No surface change after 24 hours of immersion | GB/T 1734 |
| Anti-Stone Impact | Anti-Stone Impact Tester | W3 | SAEJ400 |
Send product request
