Ral9016 White Color Powder Coating
Gloss and color Range
5%-99% and above depending on the end requirement
Full color range isavailable.
Feature
Specific gravity
1.2-1.5g/cm3 (varied with different color and gloss)
Particle size
average 10~38um, proportion 10~84um{>}90%,it
can be adiusted if special requirement is put
Gloss & Color Range
| Item | Details |
|---|---|
| Gloss Levels | 5%–95% and above (customizable) |
| Color Options | Full color range available |
Application Scenarios
| Industry | Examples |
|---|---|
| Racking Industry | Storage racks, supermarket racks, pallet racks, racking systems |
| Metal Furniture | Steel furniture, document cabinets |
| Aluminium Extrusion | Aluminium profiles, aluminium products |
| Gas Cylinders | Gas cylinders, gas tanks |
| Electrical Industry | Electric cabinets, electric panels |
| Metal Doors | Iron doors, steel doors, security doors, rolling shutter doors |
Technical Parameters
| Parameter | Details |
|---|---|
| Specific Gravity | 1.2–1.9 g/cm³ (varies by color and gloss) |
| Particle Size | Average 10–84 μm, >90% within range (adjustable for special requirements) |
| Application Method | Electrostatic spraying |
| Curing Schedule | 10 minutes at 180°C (metal temperature), or customizable |
| Optimal Film Thickness | Smooth: 60–90 μmSandy texture: 70–120 μmHammer texture: 150–350 μm |
| Average Coverage Rate | Smooth surface: 6–12 m²/kg (60 μm thickness)Texture surface: 5–7 m²/kg (120 μm thickness) |
Pretreatment Requirements
| Substrate | Recommended Pretreatment |
|---|---|
| Aluminium | Chromate conversion |
| Steel | Zinc phosphate |
| Zinc-coated steel | Zinc phosphate or chromate conversion |
