Ral9016 White Color Powder Coating

Gloss and color Range

5%-99% and above depending on the end requirement

Full color range isavailable.

Feature

Specific gravity

1.2-1.5g/cm3 (varied with different color and gloss)

Particle size

average 10~38um, proportion 10~84um{>}90%,it

can be adiusted if special requirement is put

Gloss & Color Range

ItemDetails
Gloss Levels 5%–95% and above (customizable)
Color Options Full color range available

Application Scenarios

IndustryExamples
Racking Industry Storage racks, supermarket racks, pallet racks, racking systems
Metal Furniture Steel furniture, document cabinets
Aluminium Extrusion Aluminium profiles, aluminium products
Gas Cylinders Gas cylinders, gas tanks
Electrical Industry Electric cabinets, electric panels
Metal Doors Iron doors, steel doors, security doors, rolling shutter doors

Technical Parameters

ParameterDetails
Specific Gravity 1.2–1.9 g/cm³ (varies by color and gloss)
Particle Size Average 10–84 μm, >90% within range (adjustable for special requirements)
Application Method Electrostatic spraying
Curing Schedule 10 minutes at 180°C (metal temperature), or customizable
Optimal Film Thickness Smooth: 60–90 μmSandy texture: 70–120 μmHammer texture: 150–350 μm
Average Coverage Rate Smooth surface: 6–12 m²/kg (60 μm thickness)Texture surface: 5–7 m²/kg (120 μm thickness)

Pretreatment Requirements

SubstrateRecommended Pretreatment
Aluminium Chromate conversion
Steel Zinc phosphate
Zinc-coated steel Zinc phosphate or chromate conversion
